Morrill

Unit Bearing Motor, ECM, CWLE, 1/4 In. L

product price: $131.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Motor Sub Application Refrigerator/Freezer
  • Output Watts 25 W
  • HP 1/30
  • RPM Range 1,501-1,600
  • Voltage Compatibility 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
See all product information

Product Information

Dimensions

Body Dia. 3 7/16 in
Overall Length 3 7/8 in
Shaft Length 5/16 in
Shaft Dia. 1/4 in
Length Less Shaft 3 1/2 in
Bolt Circle Dia. 2 13/16 in
Lead Length 15 in

Details

Motor Sub Application Refrigerator/Freezer
Output Watts 25 W
HP 1/30
RPM Range 1,501-1,600
Voltage Compatibility 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Phase Single
Voltage 115V AC
Motor Shaft Rotation CCWSE
Nameplate RPM 1,550
Frame Non-Standard
Max. Ambient Temp. 55 Degrees C
Motor Enclosure Design Totally Enclosed Air-Over
Application Beverage Merchandisers and Vending Machines, Condenser Fans, Ice Machines, Walk-in Coolers and Freezers
Motor Frame Material Aluminum
Motor Mounting Type Rear/Foot
Motor Service Factor 1
Duty Continuous
Motor Thermal Protection Electronic
Motor Design ECM
Plug Type 2 Prong Lyall M-2-24
Mounting Pattern (4) Orificios Perforados de 0.147 in dia 5/8 x 1-1/8 in en cada Pata, (5) Orificios Perforados de 0.15 in dia en Círculo de Perno de 2.813 in dia en la Parte Posterior
Motor Shaft Design Threaded
Motor Bearings Unit
Standards CSA, UL
No. of Speeds 1
Item ECM Unit Bearing Motor
Motor Mounting Position All Angle
Ins. Class B
Motor Application HVAC/R
Hz 60 Hz
Ambient Temperature -40 to 55 Degrees C
Full Load Amps 0.6 A
Green Environmental Attribute Product Contributes To Reducing Energy Consumption
Frame Material Aluminum
Mounting Stud Pattern 1 1/8 in x 5/8 in (L, S Mounting), 2 13/16 in (E, G Mounting)
Usable @ 200V No
Stud Quantity 2 (G Mounting), 3 (E Mounting), 4 (L, S Mounting)
Features 5 Cored Holes Opposite Shaft End, Electronically Commutated (ECM), Electronically Protected, Tapped Double Boss
Weight 2 lb
Duty Cycle Continuous
Usable @ 208V No

Description

ECM Unit Bearing Motor, Single Phase, Motor Design ECM, 1/30 HP, Nameplate RPM 1,550, No. of Speeds 1, Voltage 115V AC, 0.6 A Full Load Amps, Non-Standard Frame, Output Watts 25 W, 60 Hz Hz, Usable @ 208V No, Usable @ 200V No, Motor Service Factor 1, Motor Thermal Protection Electronic, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 55 Degrees C, Motor Shaft Rotation CCWSE, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Rear/Foot, Motor Frame Material Aluminum
