Shop MULTIFAN

Agricultural Exhaust Fan, 240V, 21/32 HP

  • Mfr # C6E63K0M10338
  • Zoro # G9900055
product price:
$
1,652.99
/ea
Additional $100.00 delivery surcharge applies per item.
See details

Key Features

Type
Preassembled High Efficiency, Direct Drive, Cone
Phase
1
Height (In.)
34 5/8 in
Voltage
240
Motor Enclosure
Totally Enclosed Air Over
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
C6E63K0M10338
Zoro #
G9900055
UPC #
-
Country of Origin
Netherlands

Dimensions

Height (In.)
34 5/8 in
Max. Depth (In.)
35 3/4 in
Width (In.)
34 5/8 in
Propeller Dia. (In.)
24 in
Flange Width (In.)
2 in
Venturi Depth (In.)
8 1/4 in
Cone Dia. (In.)
35 3/4 in
Flange Width
2 in
Overall Diameter
35 3/4 in
For Cut-Out Height
30 3/4 in
Overall Depth
35 3/4 in
Overall Width
34 5/8 in
For Cut-Out Width
30 3/4 in
Overall Height
34 5/8 in
Manufacturer Warranty Length
3 yr
Blade Diameter
24 in

Details

Type
Preassembled High Efficiency, Direct Drive, Cone
Phase
1
Voltage
240
Motor Enclosure
Totally Enclosed Air Over
Bearing Type
Permanently Lubricated Sealed Ball
Number of Blades
5
Motor RPM
1125
CFM @ 0.150-In. SP
7010
CFM @ 0.050-In. SP
7820
Full Load Amps
2.4 A
HP
2/3 hp
Hz
60 Hz
Fan RPM
1,125
Item
Agricultural Exhaust Fan
Motor Insulation
Class F
Includes
Cone, Exhaust Screen, Housing, Instructions, Intake Shutter
Watts
544 W
CFM/Watt @ 0.000-In. SP
15.0
Propeller Material
Polypropylene
Frame Finish
Polished
Opening Required W (In.)
30 3/4 in
Opening Required H (In.)
30 3/4 in
CFM @ 0.000-In. SP
8170
CFM @ 0.100-In. SP
7420
Mounting Location
Wall
Frame Material
Fiberglass
Max. Ambient Temp. (F)
104 Degrees F
Motor Type
3-Phase
Agency Compliance
BESS Labs, CURUS
Standards
BESS Labs, CURUS
Ventilation Type
Exhaust
Maximum Ambient Operating Temperature
104 Degrees F
Exhaust Airflow @ 0.000 in SP
8,170 cfm
Guard Finish
Smooth
Blade Material
Polypropylene
Motor Horsepower
2/3 hp
Includes Motor
Yes
Exhaust Airflow @ 0.100 in SP
7,420 cfm
Nameplate Voltage
240V AC
Motor Speed
1,125 RPM
Exhaust Airflow @ 0.125 in SP
1,993 cfm
Assembled
Unassembled

Description

Agricultural Exhaust Fan, Assembled Unassembled, Blade Diameter 24 in, Blade Material Polypropylene, Exhaust Airflow @ 0.000 in SP 8,170 cfm, For Cut-Out Height 30 3/4 in, For Cut-Out Width 30 3/4 in, Frame Finish Polished, Frame Material Fiberglass, Guard Finish Smooth, Includes Cone, Exhaust Screen, Housing, Instructions, Intake Shutter
