Stainless Steel Four Bolt Flange
Mfr # SUCF204-12
Zoro # G123655030
product price:Â
$
192.99
/ea
Free Shipping & Returns
Key Features
Shaft Locking Type
Set Screws
Number of Mount Holes
4
Bearing Material Grade
440C
Mount Hole Size
0.47 in
Load Direction
Radial
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- SUCF204-12
- Zoro #
- G123655030
- UPC #
- -
- Country of Origin
- Multiple
Dimensions
- Mount Hole Size
- 0.47 in
- Overall Width
- 1 19/64 in
- Overall Length
- 3 3/8 in
- Mounting Bolt Size
- 3/8, M10
- Center Height
- 1 11/16 in
- Back Side to Center Width
- 1.31 in
- Bore Diameter
- 3/4 in
- Flange Thickness
- 15/32 in
- Inner Ring Width
- 1.22 in
- Mount Hole Center-to-Center Height
- 2 33/64 in
- Overall Height
- 3 3/8 in
- Mount Hole Center-to-Center Length
- 2 33/64 in
- Length
- 3 3/8 in
Description
Flange Mount Bearing, Back Side to Center Width 1.31 in, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 3/4 in, Bore Type Cylindrical, Center Height 1 11/16 in, Closure Double Sealed, Expansion Type Fixed, For Environment Food and Beverage, Housing Material Stainless Steel, Housing Type Square, Included Bearing SUC204-12, Lubricant Material H-1 Food Grade Grease, Maximum Temperature 212 Degrees F, Minimum Temperature -4 Degrees F
