Shop NUMATICS

Solenoid Air Control Valve, 1/4 In, 120VAC

  • Mfr # 152SS400K000030

  • Zoro # G1149005

product price:
$
341.99
/ea
Free Shipping & Returns

Key Features

Body Style
Base-Mounted
Series
Mark 15
Voltage
110 to 120V AC
Valve Actuator / Return
Solenoid / Solenoid
Pilot Pressure
20 psi
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
152SS400K000030
Zoro #
G1149005
UPC #
-
Country of Origin
United States

Dimensions

Overall Height
3 5/16 in
Overall Width
2 5/32 in
Pipe Size
1/4 in
Overall Length
8 7/8 in
Pilot Port Size
1/4 in NPT
Pilot Port Connection Size
1/4 in
Inlet Port Connection Size
1/4 in
Wire Rope Length
8 7/8 in
Length
8 7/8 in

Details

Item
Solenoid Air Control Valve
Body Style
Base-Mounted
Series
Mark 15
Voltage
110 to 120V AC
Valve Actuator / Return
Solenoid / Solenoid
Pilot Pressure
20 psi
Power Consumption
0.58 W
Coefficient of Volume
1.5
Vacuum Range
0 to 28" Hg
Body Material
Steel
Override
Non-Locking
Actuator/Return
Solenoid/Solenoid
Electrical Connections
AC Plug-In w/Light
Valve Ways and Positions
4-Way/2-Position
Standards
CE Certified, CSA Certified, RU
CFM
69
Max. CFM - Valves
69 cfm
Ambient Temp. Range
-10 Degrees to 115 Degrees F
Shifting Technology
Spool & Sleeve
Pressure Range
0 to 150 psi
Operational Pressure Range
0 to 150 psi
NEMA Classification
NEMA 4
Air Valve Type
4-Way, 2-Position
Valve Vacuum Range
0 to 28 in Hg
Number of Positions
Two-Position
Number of Ways
Four-Way
Number of Ports
5
Operating Pressure - Maximum
150 psi
Inlet Port Connection Type
NPT
Includes Solenoid Coil
Solenoid Coil Included
Product Type
Solenoid Air Control Valve
Actuator Type
Double Solenoid
Exhaust Port Connection Gender
Female
Inlet Port Connection Gender
Female
Flow Rate - Maximum
161 cfm
Pilot Port Connection Type
NPT
Poppet Material
Aluminum
Vacuum Rating
Vacuum Operable
Operating Temperature - Maximum
115 Degrees F
Pilot Port Connection Gender
Female
Operating Temperature - Minimum
-10 Degrees F
Spool Material
Stainless Steel
Duty Cycle
Continuous
Coefficient of Volume (Cv)
1.4
Pilot Type
Internal Pilot, Remote Pilot
NEMA Rating
4
Valve Type
Spool
Includes Mounting Hardware
Hardware Not Included
Body Features
Single
Application
Automotive, Bottling, High Cycle-Rate Machines, Pressing, Stamping, Tire Manufacturing
Operating Pressure - Minimum
14 psi
Electrical Connection Type
Plug-In
For Media
Air, Inert Gas
Return Action
Solenoid Return

Description

Solenoid Air Control Valve, Valve Ways and Positions 4-Way/2-Position, Voltage 110 to 120V AC, Center Position Not Applicable, Valve Actuator / Return Solenoid / Solenoid, ISO Class Not Applicable, Pipe Size 1/4 in, Max. CFM - Valves 69 cfm, Operational Pressure Range 0 to 150 psi, NEMA Classification NEMA 4, Valve Vacuum Range 0 to 28 in Hg, Body Style Base-Mounted, Pilot Port Size 1/4 in NPT, Pilot Pressure 20 psi, Coefficient of Volume 1.5, AC Plug-In w/Light Electrical Connections
