RTD Sensor, 2.12 in w, 1.78 in H

Name: RTD Sensor, 2.12 in w, 1.78 in H
Brand: Omega
SKU: G321907955
Price: 166.99 USD
Availability: InStock

166.99

/ea

Free Shipping & Returns

Response Time

30 sec

Temperature Accuracy

20 to 80% of +/-3% RH, 5 to 20% of +/-4% RH, 80 to 95% of +/-4% RH

Features

Connects to Computer, Data Logger, or Industrial Controller/Meter, Thermocouple, RTD, or Thermistor Sensor Models

Compensated Temperature - Minimum

-15 Degrees C

Standards

RoHS

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Get 10% off your order

Specifications

MFR #: EWS-RTD
Zoro #: G321907955
UPC #: -
Country of Origin: United States
Response Time: 30 sec
Temperature Accuracy: 20 to 80% of +/-3% RH, 5 to 20% of +/-4% RH, 80 to 95% of +/-4% RH
Features: Connects to Computer, Data Logger, or Industrial Controller/Meter, Thermocouple, RTD, or Thermistor Sensor Models
Compensated Temperature - Minimum: -15 Degrees C
Standards: RoHS
Humidity Measurement - Minimum: 5 %
Humidity Measurement - Maximum: 95 %
Operating Temperature - Minimum: 32 Degrees F
Humidity Accuracy: 20 to 80% of +/-3% RH; 5 to 20% of +/-4% RH; 80 to 95% of +/-4% RH
Input Voltage: 12 to 24V DC
Display Screen Type: No Display
Compensated Temperature - Maximum: 77 Degrees F
Item: RTD Sensor
Series: EWS
Temperature Sensor: Thin-Film Polymer Capacitor
Output Power: 4 to 20mA/1 to 5V DC
Process Media Temperature Measurement - Minimum: -15 Degrees C
Process Media Temperature Measurement - Maximum: 140 Degrees F
Operating Temperature - Maximum: 140 Degrees F
Mounting Style: Wall Mount
Enclosure Material: Acrylonitrile Butadiene Styrene
Electrical Connection: Screw Terminals
