Temperature and Humidity Transmitter: 4 to 20mA/1 to 5V DC, Thin-Film Polymer Capacitor, EWS

  • Mfr # EWS-RH
  • Zoro # G021909051
product price:
$
395.99
/ea
Free Shipping & Returns
Zoro's best price: not eligible for any other offers or promotions

Key Features

Overall Height
1.78 in
Compensated Temperature - Minimum
-15 Degrees C
Series
EWS
Process Media Temperature Measurement - Minimum
-15 Degrees C
Output Power
4 to 20mA/1 to 5V DC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
EWS-RH
Zoro #
G021909051
UPC #
-
Country of Origin
United States

Dimensions

Overall Height
1.78 in
Overall Length
3.12 in
Manufacturers Warranty Length
1 yr
Overall Width
2.12 in
Wire Rope Length
3.12 in
Length
3.12 in

Details

Compensated Temperature - Minimum
-15 Degrees C
Series
EWS
Process Media Temperature Measurement - Minimum
-15 Degrees C
Output Power
4 to 20mA/1 to 5V DC
Temperature Sensor
Thin-Film Polymer Capacitor
Display Screen Type
No Display
Humidity Measurement - Minimum
5 %
Humidity Measurement - Maximum
95 %
Enclosure Material
Acrylonitrile Butadiene Styrene
Input Voltage
12 to 24V DC
Response Time
30 sec
Item
Temperature and Humidity Transmitter
Compensated Temperature - Maximum
77 Degrees F
Features
Connects to Computer, Data Logger, or Industrial Controller/Meter, Thermocouple, RTD, or Thermistor Sensor Models
Mounting Style
Wall Mount
Humidity Accuracy
20 to 80% of +/-3% RH; 5 to 20% of +/-4% RH; 80 to 95% of +/-4% RH
Temperature Accuracy
20 to 80% of +/-3% RH, 5 to 20% of +/-4% RH, 80 to 95% of +/-4% RH
Electrical Connection
Screw Terminals
Operating Temperature - Maximum
140 Degrees F
Process Media Temperature Measurement - Maximum
140 Degrees F
Operating Temperature - Minimum
32 Degrees F

Description

WALL MT TEMP/HUMIDITY TRANS

Restrictions

This item has been restricted from sale in the following states: CA
