  11. LogicController, 6Inputs, 4Outputs, 8KB
No Product Image Available

LogicController, 6Inputs, 4Outputs, 8KB

  • Mfr # CP1E-E10DT-A

  • Zoro # G508273774

product price: $428.99
/ea
Free Shipping & Returns

Key Features

Output Type
(4) NPN
Number of Outputs
4
Number of Inputs
6
Features
High Speed Counters, Input Interrupts, PWM Outputs for Transistor Output, Pulse Control for Transistor Output
Depth
85 mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
CP1E-E10DT-A
Zoro #
G508273774
UPC #
4547648800808
Country of Origin
China

Dimensions

Depth
85 mm
Height
110 mm
Width
66 mm
Overall Depth
3.35 in
Overall Width
2.6 in
Overall Height
4.33 in

Details

Item
PLC
Output Type
(4) NPN
Number of Outputs
4
Number of Inputs
6
Features
High Speed Counters, Input Interrupts, PWM Outputs for Transistor Output, Pulse Control for Transistor Output
Counters
256
Description/Special Features
Built-In Analog I/O, Two Inputs and One Output, for NA-type CPU Units, Complete High-Speed Counter Functionality, Easy Connection, Input Interrupts, Mounting Serial Option Boards, Ethernet Option Board and Analog Option Board to N30/40/60 or NA20 CPU Units
Memory
2 KWords
Input Voltage
100 to 240 V AC
Display
7 Segment LED
Amps
0.11 A
Clock
No
Timers
256
Port Type
USB
Product Type
Programmable Logic Controller
Display Type
No Display
Memory Capacity
8 KB
Mounting Style
Panel
Clock Included
Clock Not Included
Input Circuit Current - Maximum
40 A
Output Circuit Current - Maximum
0.3 A
Number of Timers
256
Expandability
Expandable
Number of Counters
256
AC Voltage Rating
100 to 240V AC
Current
300 mA
Series
CP1E

Description

PLC, Input Voltage 100 to 240 V AC, Output Type (4) NPN, 0.11 A Amps, Number of Inputs 6, Number of Outputs 4, Counters 256, Timers 256, No Clock, 7 Segment LED Display, Port Type USB, Memory 2 KWords, Built-In Analog I/O, Two Inputs and One Output, for NA-type CPU Units, Complete High-Speed Counter Functionality, Easy Connection, Input Interrupts, Mounting Serial Option Boards, Ethernet Option Board and Analog Option Board to N30/40/60 or NA20 CPU Units, Depth 85 mm, Height 110 mm, Width 66 mm
