Solid State Relay, 3 Phase, Screw, DIN Track, Phototriac
Mfr # G3PE-525B-3N DC12-24
Zoro # G910087730
product price:Â
$
443.99
/ea
Free Shipping & Returns
Key Features
Electrical Phase
3
Electrical Connection
Screw
Mounting Style
DIN Track
Switch Component Type
Phototriac
Heat Sink
Integral
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- G3PE-525B-3N DC12-24
- Zoro #
- G910087730
- UPC #
- 4548583410046
- Country of Origin
- United States
Dimensions
- Overall Depth
- 6.1 in
- Body Depth
- 6.1 in
- Body Height
- 4.72 in
- Body Width
- 3.14 in
Details
- Item
- Solid State Relay
- Electrical Phase
- 3
- Electrical Connection
- Screw
- Mounting Style
- DIN Track
- Switch Component Type
- Phototriac
- Heat Sink
- Integral
- Input Voltage
- 9.6 to 30V DC
- Standards
- CE Certified, CSA, EN, TUV, UL Listed
- Insulation Resistance
- 100 megaohm at 500V DC
- Dielectric Strength
- 2,500V AC
- Current Type
- DC
- Output Voltage Range
- 180 to 528V AC
- Minimum Operating Temperature
- -30 Degrees C
- Response Time
- 1 msec
- Status Indicator
- Equipped
- Drop Out Voltage
- 1.8V
- Input Current
- 10 mA
- Maximum Operating Temperature
- 80 Degrees C
- Weight
- 1,450 g
- Series
- G3PE
Description
Contactors - Solid State, Electrical Connection Screw, Heat Sink Integral, Input Current 10 mA, Input Voltage 9.6 to 30V DC, Output Voltage Range 180 to 528V AC, Standards CE Certified, CSA, EN, TUV, UL Listed, Switch Component Type Phototriac, Current Type DC, Electrical Phase Three, Mounting Style DIN Track, Voltage Type DC Output, Body Depth 6.1 in, Body Height 4.72 in, Body Width 3.14 in, Dielectric Strength 2,500V AC, Drop Out Voltage 1.8V, Insulation Resistance 100 megaohm at 500V DC
