  11. Male Disconnect, Yellow, 12-10AWG, PK500
Panduit Male Disconnect, Yellow, 12-10AWG, PK500 DNF10-250FIMB-D - main

Male Disconnect, Yellow, 12-10AWG, PK500

  • Mfr # DNF10-250FIMB-D

  • Zoro # G0287990

product price: $414.99
/pk 500, $0.83/ea
Free Shipping & Returns

Key Features

Insulation
Full
Insulation Color
Yellow
Insulation Type
Nylon
Connection Type
Crimp
Wire Range
12 to 10 AWG
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
DNF10-250FIMB-D
Zoro #
G0287990
UPC #
074983785070
Country of Origin
Mexico

Dimensions

Tab Size
0.032 in x 0.250 in
Overall Length
0.96 in
Barrel Inside Dia.
0.138 in
Barrel Size
Standard
Minimum Wire Size
12 AWG
Tab Thickness
0.032 in
Maximum Wire Size
10 AWG
Strip Length
1/4 in
Tab Width
0.25 in
Barrel Inside Diameter
0.138 in

Details

Item
Male Disconnect
Insulation
Full
Insulation Color
Yellow
Insulation Type
Nylon
Connection Type
Crimp
Wire Range
12 to 10 AWG
Seam
Butted
Max. Voltage
600 V
Max. Temp.
221 Degrees F
Connection Material
Nickel-Plated Copper
Standards
C22.2 No.153, CSA Certified LR31212, UL 310 Listed, UL Listed 20H3 E78522
Disconnect Style
Tab
Contact Finish
Nickel
Minimum Operating Temperature
-60 Degrees F
Maximum Voltage
600 V
Special Features
Disconnect can be Inserted and Removed From the Male Tab Without the Use of Tools for Lower Installed Cost, Fully Insulated Design Provides Protection From Electrical Shorts, Internal Barrel Serrations Assure Good Wire Contact and Maximum Tensile Strength, Internal Wire Stop Assures Proper Length of Insertion Into Terminal Barrel, Providing a Higher Quality Connection
UL 94 Flammability Rating
HB, V-2
Insulation Material
Nylon
Seam Style
Butted
RoHS Compliant
Yes
Contact Material
Copper
Termination Style
Crimp
Terminal Type
Tab
Insulation Coverage
Full Coverage
Maximum Operating Temperature
221 Degrees F

Description

Wire Disconnect, Contact Finish Nickel, Contact Material Copper, Disconnect Style Quick Disconnect, Insulation Color Yellow, Insulation Coverage Full Coverage, Insulation Material Nylon, Maximum Temperature 221 Degrees F, Minimum Wire Size 12 AWG, Maximum Wire Size 10 AWG, Maximum Voltage 600 V, Tab Thickness 0.032 in, Tab Width 0.25 in, Terminal Type Tab, Termination Style Crimp, UL 94 Flammability Rating HB, V-2, RoHS Compliant Yes, Seam Style Butted
