Panduit Mechanical Lug, 1/0 AWG Max, 2 Hole, Aluminum LAM3B1/0-38-6Y - main

Mechanical Lug, 1/0 AWG Max, 2 Hole, Aluminum

  • Mfr # LAM3B1/0-38-6Y

  • Zoro # G0771080

product price:  $37.59
/ea

Key Features

For Conductor Material
Aluminum, Copper
For Minimum Wire Size
14 AWG
For Maximum Wire Size
1/0 AWG
Number of Terminations
3
Number of Holes
2
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
LAM3B1/0-38-6Y
Zoro #
G0771080
UPC #
7498359289
Country of Origin
United States

Dimensions

For Minimum Wire Size
14 AWG
For Maximum Wire Size
1/0 AWG
Height
0.9 in
Overall Length
2.91 in
Stud Hole Size (In.)
44993
Overall Height (In.)
0.9
Tongue Thickness (mm)
6.4
Overall Height (mm)
16
Overall Length (In.)
2.91
Overall Length (mm)
74.7
Tongue Thickness (In.)
0.25
Tongue Length
2.16 in

Details

Item
Mechanical Lug
For Conductor Material
Aluminum, Copper
Number of Terminations
3
Number of Holes
2
Body Material
Aluminum
Contact Finish
Tin
Maximum Voltage
600 V
Maximum Operating Temperature
194 Degrees F
Standards
UL Listed and CSA Certified
Stud Hole Spacing (In.)
1
Stud Hole Spacing (mm)
25.4
Finish/Coating
Tin-Plated
Product Type
Mechanical Connectors - Lug
Tongue Type
Straight Tongue
UL Temperature Rating (°C)
90
Connector Plating
Tin
Product Material
Copper, Aluminum
Product Name
Terminal Connector
Product Class
Wire Termination

Description

Lug Compression Connector,14-1/0 AWG
