One-Hole Compression Lug, 1 to 2 in Stud, Standard Barrel, Copper, White
Mfr # LCAF250-12-X
Zoro # G2769194
product price: $17.19
/eaKey Features
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Standard
Tongue Width
1.28 in
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
LCAF250-12-X
Zoro #
G2769194
UPC #
7498355797
Country of Origin
Mexico
Dimensions
For Stud Size
1 to 2 in
Barrel Size
Standard
Tongue Width
1.28 in
Length
5.4"
Overall Length
3.3 in
Class K Copper Flex Conductor Size (kcmil)
250
Tongue Width (In.)
1.28
Barrel Length (mm)
42
Tongue Width (mm)
32.5
Wire Strip Length (In.)
1.75
Tongue Thickness (mm)
4.3
Stud Hole Size (In.)
1 to 2
Overall Length (In.)
3.3
Wire Strip Length (mm)
44.5
Barrel Length (In.)
1.65
Class M Copper Flex Conductor Size (kcmil)
250
DLO Copper Flex Conductor Size (kcmil)
262.6
Tongue Thickness (In.)
0.17
Overall Length (mm)
83.8
Stud Hole Size (mm)
12.7
Description
Copper Compression Lug, 1 Hole, 250 kcmil, Flared Barrel, 1/2 (12.7mm) Stud
