  11. One-Hole Compression Lug, 750 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Black
Panduit One-Hole Compression Lug, 750 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Black LCCN750-12W-6 - main

One-Hole Compression Lug, 750 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Black

  • Mfr # LCCN750-12W-6

  • Zoro # G2796887

product price: $82.19
/ea
Free Shipping & Returns

Key Features

For Wire Size
750 kcmil
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCCN750-12W-6
Zoro #
G2796887
UPC #
7498344995
Country of Origin
Mexico

Dimensions

For Wire Size
750 kcmil
For Stud Size
1 to 2 in
Barrel Size
Long
Tongue Width
1.31 in
Overall Length
6.66 in
Length
6.7"
Copper Conductor Size (kcmil)
750
Barrel Length (In.)
2.88
Overall Length (mm)
169.2
Overall Length (In.)
6.66
Tongue Thickness (mm)
7.1
Wire Strip Length (mm)
74.6
Stud Hole Size (In.)
1 to 2
Tongue Width (mm)
33
Tongue Width (In.)
1.3
Tongue Thickness (In.)
0.28
Wire Strip Length (In.)
2.9375
Copper Code Conductor Size (kcmil)
750
Barrel Length (mm)
73.2
Stud Hole Size (mm)
12.7

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
24
Color Code
Black
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Features
Corrosion Resistant
Finish/Coating
Tin-Plated
Stud Hole Spacing (In.)
1.75
Product Type
Copper Compression Connectors - Lugs
Stud Hole Spacing (mm)
44.5
UL Temperature Rating (°C)
90
Burndy Die Index Number
24
Panduit Die Index Number
P106
Maximum Voltage (kV)
35
Tongue Type
Narrow
Base Material
Copper
Product Material
Copper
Product Name
Terminal Connector
Connector Details
1 x Terminal
Connector Plating
Tin
Product Class
Wire Termination

Description

Copper Compression Lug, 2 Hole, 750 kcmil, Narrow Tongue, 1/2 (12.7mm) Stud
