  11. Two-Hole Compression Lug, 2/0 AWG Max, 1/4 in Stud, Standard Barrel, Copper, Black
Panduit Two-Hole Compression Lug, 2/0 AWG Max, 1/4 in Stud, Standard Barrel, Copper, Black LCD2/0-14A-X - main

Two-Hole Compression Lug, 2/0 AWG Max, 1/4 in Stud, Standard Barrel, Copper, Black

  • Mfr # LCD2/0-14A-X

  • Zoro # G0777283

product price: $11.86
/ea

Key Features

Cable Size
2/0 AWG
Connector Type
Standard Barrel
Width
0.85"
Material
Copper
Length
2.7"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCD2/0-14A-X
Zoro #
G0777283
UPC #
7498338324
Country of Origin
Mexico

Dimensions

Cable Size
2/0 AWG
Width
0.85"
Length
2.7"
Overall Length
2.7 in
Barrel Length (mm)
24.9
Copper Code Conductor Size (AWG)
36557
Tongue Width (mm)
21.6
Barrel Length (In.)
0.98
Stud Hole Size (In.)
44930
Inside Diameter (In.)
0.45
Outer Diameter (mm)
14.73
Stud Hole Size (mm)
6.4
Outer Diameter (In.)
0.58
Wire Strip Length (mm)
26.9
Tongue Thickness (In.)
0.13
Overall Length (mm)
68.6
Tongue Thickness (mm)
3.3
Tongue Width (In.)
0.85
Overall Length (In.)
2.7
Inside Diameter (mm)
11.43
Wire Strip Length (In.)
42370
Barrel Size
Standard
Tongue Width
0.85 in
For Wire Size
2/0 AWG
For Stud Size
1/4 in

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Black
Item
Two-Hole Compression Lug
Die Code
13
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Features
Corrosion Resistant
Connection Material
Tin
Connection Type
1 x Terminal
Lug Type
2 Stud Hole Lug
Base Material
Copper
Tongue Angle
Straight
Maximum Voltage (kV)
35
Stud Hole Spacing (mm)
16
UL Temperature Rating (°C)
90
Stud Hole Spacing (In.)
0.63
Finish/Coating
Tin-Plated
Panduit Die Index Number
P45
T & B Die Index Number
13
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Burndy Die Index Number
13
Product Name
Terminal Connector
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,2/0 AWG

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
