  11. Two-Hole Compression Lug, 250 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Yellow
Panduit Two-Hole Compression Lug, 250 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Yellow LCCX250-12-X - main

Two-Hole Compression Lug, 250 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Yellow

  • Mfr # LCCX250-12-X

  • Zoro # G0423821

product price: $23.99
/ea

Key Features

For Wire Size
250 kcmil
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCCX250-12-X
Zoro #
G0423821
UPC #
7498319825
Country of Origin
Mexico

Dimensions

For Wire Size
250 kcmil
For Stud Size
1 to 2 in
Barrel Size
Long
Tongue Width
1.28 in
Cable Size
250 kcmil
Length
5.77"
Width
1.28"
Overall Length
5.77 in
Overall Length (In.)
5.77
Stud Hole Size (mm)
12.7
Outer Diameter (In.)
0.88
Wire Strip Length (mm)
58.7
Outer Diameter (mm)
22.35
DLO Copper Flex Conductor Size (kcmil)
262.6
Barrel Length (mm)
56.9
Tongue Thickness (In.)
0.17
Inside Diameter (mm)
17.78
Tongue Width (mm)
32.5
Overall Length (mm)
146.6
Inside Diameter (In.)
0.7
Tongue Thickness (mm)
4.3
Barrel Length (In.)
2.24
Tongue Width (In.)
1.28
Stud Hole Size (In.)
1 to 2
Wire Strip Length (In.)
42405

Details

Item
Two-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
16
Color Code
Yellow
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Long Barrel
Hole Center to Center
1.75 in
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant
Tongue Type
Standard
Finish/Coating
Tin-Plated
UL Temperature Rating (°C)
90
Lug Type
2 Stud Hole Lug
Product Type
Copper Compression Connectors - Lugs
Burndy Die Index Number
16
T & B Die Index Number
16
Panduit Die Index Number
P62
Stud Hole Spacing (mm)
44.5
Base Material
Copper
Stud Hole Spacing (In.)
1.75
Maximum Voltage (kV)
35
Connector Details
1 x Terminal
Product Name
Terminal Connector
Product Material
Copper
Connector Plating
Tin
Product Class
Wire Termination
Number of Holes
2

Description

Lgflex Lug,250mcm,1.75in Space,Wdw
