  11. Two-Hole Compression Lug, 250 kcmil Max, Standard Barrel, Copper, Yellow
Panduit Two-Hole Compression Lug, 250 kcmil Max, Standard Barrel, Copper, Yellow LCD250-38D-X - main

Two-Hole Compression Lug, 250 kcmil Max, Standard Barrel, Copper, Yellow

  • Mfr # LCD250-38D-X

  • Zoro # G0777301

product price: $20.15
/ea

Key Features

Cable Size
250 kcmil
Connector Type
Standard Barrel
Width
1.17"
Material
Copper
Length
3.54"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCD250-38D-X
Zoro #
G0777301
UPC #
7498338332
Country of Origin
Mexico

Dimensions

Cable Size
250 kcmil
Width
1.17"
Length
3.54"
Overall Length
3.54 in
Stud Hole Size (In.)
44993
Inside Diameter (mm)
16
Barrel Length (In.)
1.25
Copper Code Conductor Size (kcmil)
250
Outer Diameter (In.)
0.77
Barrel Length (mm)
31.8
Outer Diameter (mm)
19.55
Tongue Width (In.)
1.17
Wire Strip Length (mm)
33.3
Wire Strip Length (In.)
42374
Overall Length (In.)
3.54
Tongue Width (mm)
29.7
Inside Diameter (In.)
0.63
Stud Hole Size (mm)
9.5
Tongue Thickness (mm)
3.6
Tongue Thickness (In.)
0.14
Overall Length (mm)
89.9
For Wire Size
250 kcmil
Tongue Width
1.17 in
Barrel Size
Standard

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Yellow
Item
Two-Hole Compression Lug
Die Code
16
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Features
Corrosion Resistant
Connection Type
1 x Terminal
Connection Material
Tin
Maximum Voltage (kV)
35
Stud Hole Spacing (mm)
25.4
Burndy Die Index Number
16
Product Type
Copper Compression Connectors - Lugs
T & B Die Index Number
16
Finish/Coating
Tin-Plated
Base Material
Copper
UL Temperature Rating (°C)
90
Lug Type
2 Stud Hole Lug
Tongue Angle
Straight
Tongue Type
Standard
Panduit Die Index Number
P62
Stud Hole Spacing (In.)
1
Product Name
Terminal Connector
Product Material
Copper
Connector Details
1 x Terminal
Connector Plating
Tin
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,250 Kcmil

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
