Shop PANDUIT

Two-Hole Compression Lug, 350 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Red

  • Mfr # LCC350-12W-X

  • Zoro # G0413680

product price:  $27.25
/ea

Key Features

For Wire Size
350 kcmil
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCC350-12W-X
Zoro #
G0413680
UPC #
7498379843
Country of Origin
Mexico

Dimensions

For Wire Size
350 kcmil
For Stud Size
1 to 2 in
Barrel Size
Long
Tongue Width
1.28 in
Cable Size
350 kcmil
Length
5.76"
Width
1.28"
Overall Length
5.76 in
Outer Diameter (mm)
22.35
Inside Diameter (mm)
17.78
Wire Strip Length (mm)
58.7
Tongue Thickness (mm)
4.3
Overall Length (In.)
5.76
Outer Diameter (In.)
0.88
Barrel Length (mm)
56.9
Barrel Length (In.)
2.24
Tongue Thickness (In.)
0.17
Copper Code Conductor Size (kcmil)
350
Stud Hole Size (In.)
1 to 2
Stud Hole Size (mm)
12.7
Tongue Width (In.)
1.28
Inside Diameter (In.)
0.7
Overall Length (mm)
146.3
Tongue Width (mm)
32.5
Wire Strip Length (In.)
42405

Details

Item
Two-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
18
Color Code
Red
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Long Barrel
Color
Red
Connection Material
Tin
Connection Type
1 x Barrel Plug
Features
Corrosion Resistant
Panduit Die Index Number
P71
Stud Hole Spacing (mm)
44.5
T & B Die Index Number
18
Burndy Die Index Number
18
Stud Hole Spacing (In.)
1.75
Maximum Voltage (kV)
35
Tongue Type
Standard
Base Material
Copper
UL Temperature Rating (°C)
90
Lug Type
2 Stud Hole Lug
Product Type
Copper Compression Connectors - Lugs
Finish/Coating
Tin-Plated
Product Material
Copper
Connector Details
1 x Barrel Plug
Product Color
Red
Product Name
Terminal Connector
Connector Plating
Tin
Product Class
Wire Termination
Number of Holes
2

Description

Two-hole, long barrel lug with window, 350 kcmil, 1/2 stud hole, 1.75 hole spacing.
