  11. Two-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Purple
Panduit Two-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Purple LCC4/0-12W-X - main

Two-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Purple

  • Mfr # LCC4/0-12W-X

  • Zoro # G0775831

product price: $17.89
/ea

Key Features

Cable Size
4/0 AWG
Connector Type
Long Barrel
Width
1.06"
Material
Copper
Length
4.95"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCC4/0-12W-X
Zoro #
G0775831
UPC #
7498381902
Country of Origin
Mexico

Dimensions

Cable Size
4/0 AWG
Width
1.06"
Length
4.95"
Overall Length
4.95 in
Stud Hole Size (mm)
12.7
Overall Length (mm)
125.7
Barrel Length (In.)
1.56
Inside Diameter (In.)
0.57
Wire Strip Length (mm)
41.2
Outer Diameter (mm)
18.03
Stud Hole Size (In.)
1 to 2
Copper Code Conductor Size (AWG)
36617
Overall Length (In.)
4.95
Tongue Width (In.)
1.06
Tongue Thickness (In.)
0.14
Barrel Length (mm)
39.6
Wire Strip Length (In.)
39452
Inside Diameter (mm)
14.47
Tongue Width (mm)
26.9
Tongue Thickness (mm)
3.6
Outer Diameter (In.)
0.71
Barrel Size
Long
For Wire Size
4/0 AWG
Tongue Width
1.06 in
For Stud Size
1 to 2 in

Details

Connector Type
Long Barrel
Material
Copper
Color Code
Purple
Item
Two-Hole Compression Lug
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Die Code
15
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant
Finish/Coating
Tin-Plated
Panduit Die Index Number
P54
Tongue Type
Standard
Maximum Voltage (kV)
35
Stud Hole Spacing (mm)
44.5
T & B Die Index Number
15
Lug Type
2 Stud Hole Lug
Stud Hole Spacing (In.)
1.75
Tongue Angle
Straight
Base Material
Copper
Burndy Die Index Number
15
UL Temperature Rating (°C)
90
Product Type
Copper Compression Connectors - Lugs
Product Name
Terminal Connector
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,4/0 AWG

Restrictions
