  6. Two-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Purple
Panduit Two-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Purple LCD4/0-12-X - main

Two-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Purple

  • Mfr # LCD4/0-12-X

  • Zoro # G0777493

product price:  $18.19
/ea

Key Features

For Wire Size
4/0 AWG
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Standard
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCD4/0-12-X
Zoro #
G0777493
UPC #
7498390096
Country of Origin
Mexico

Dimensions

For Wire Size
4/0 AWG
For Stud Size
1 to 2 in
Barrel Size
Standard
Tongue Width
1.06 in
Width
1.06 in
Length
4.58 in
Cable Size
4/0 AWG
Overall Length
4.58 in
Stud Hole Size (mm)
12.7
Tongue Thickness (mm)
3.6
Barrel Length (mm)
30.2
Tongue Width (In.)
1.06
Copper Code Conductor Size (AWG)
36617
Tongue Thickness (In.)
0.14
Stud Hole Size (In.)
1 to 2
Wire Strip Length (In.)
1.25
Overall Length (In.)
4.58
Wire Strip Length (mm)
31.8
Overall Length (mm)
116.3
Tongue Width (mm)
26.9
Barrel Length (In.)
1.19

Details

Item
Two-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Die Code
15
Color Code
Purple
Connector Type
Standard Barrel
Features
Corrosion Resistant
Connection Material
Tin
Connection Type
1 x Terminal
Tongue Type
Standard
Stud Hole Spacing (In.)
1.75
Finish/Coating
Tin-Plated
Burndy Die Index Number
15
UL Temperature Rating (°C)
90
Maximum Voltage (kV)
35
Stud Hole Spacing (mm)
44.5
Base Material
Copper
Panduit Die Index Number
P54
Product Type
Copper Compression Connectors - Lugs
Product Name
Terminal Connector
Product Material
Copper
Connector Details
1 x Terminal
Connector Plating
Tin
Product Class
Lugs, Splices, Split Bolts & Accessories

Description

Lug Compression Connector,4/0 AWG
