  11. Two-Hole Compression Lug, 6 AWG Max, Long Barrel, Copper, Blue
Panduit Two-Hole Compression Lug, 6 AWG Max, Long Barrel, Copper, Blue LCC6-14A-L - main

Two-Hole Compression Lug, 6 AWG Max, Long Barrel, Copper, Blue

  • Mfr # LCC6-14A-L

  • Zoro # G0776279

product price: $8.49
/ea

Key Features

Cable Size
6 AWG
Connector Type
Long Barrel
Width
0.48"
Material
Copper
Length
2.56"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCC6-14A-L
Zoro #
G0776279
UPC #
7498338256
Country of Origin
Mexico

Dimensions

Cable Size
6 AWG
Width
0.48"
Length
2.56"
Overall Length
2.56 in
Tongue Thickness (In.)
0.08
Wire Strip Length (In.)
39448
Overall Length (mm)
65
Copper Code Conductor Size (AWG)
6
Outer Diameter (mm)
7.87
Overall Length (In.)
2.56
Tongue Width (mm)
12.2
Barrel Length (mm)
27.2
Outer Diameter (In.)
0.31
Barrel Length (In.)
1.07
Wire Strip Length (mm)
28.6
Inside Diameter (In.)
0.22
Tongue Thickness (mm)
2
Stud Hole Size (In.)
44930
Inside Diameter (mm)
5.58
Stud Hole Size (mm)
6.4
Tongue Width (In.)
0.48
Tongue Width
0.48 in
Barrel Size
Long
For Wire Size
6 AWG

Details

Connector Type
Long Barrel
Material
Copper
Color Code
Blue
Item
Two-Hole Compression Lug
Die Code
7
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Color
Blue
Connection Material
Tin
Connection Type
1 x Terminal Female
Features
Corrosion Resistant
Maximum Voltage (kV)
35
Stud Hole Spacing (In.)
0.63
UL Temperature Rating (°C)
90
Burndy Die Index Number
7
Tongue Angle
Straight
Base Material
Copper
Panduit Die Index Number
P24
Lug Type
2 Stud Hole Lug
T & B Die Index Number
7
Stud Hole Spacing (mm)
16
Finish/Coating
Tin-Plated
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Connector Details
1 x Terminal Female
Product Color
Blue
Product Name
Terminal Connector
Connector Plating
Tin
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,No.6 AWG

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
