Quick Connect Socket, Steel, 1 11/16" L
Mfr # 25SFTF10SXZ
Zoro # G810831839
Key Features
Specifications
Product Information
- MFR #
- 25SFTF10SXZ
- Zoro #
- G810831839
- UPC #
- -
- Country of Origin
- Germany
Dimensions
- Hose Fitting Size
- 3/8 in
- Barb Size
- 3/8 in
- Overall Length
- 1 11/16 in
- Body Size - Quick Connect Air Couplings
- 1/4 in
- Max. Outside Dia.
- 1/2 in
- Wire Rope Length
- 1 11/16 in
- Length
- 1 11/16 in
Details
- Item
- Quick Connect Air Coupling
- Interchange Type
- European High Flow
- Material
- Steel
- Coupling Component
- Plug
- Hose Fitting Gender
- Male
- Connection Type
- Hose Barb
- Finish/Coating
- Zinc-Plated
- Max. Flow Rate
- 110 scfm
- Coupling Locking Type
- Ball
- Seal Material
- Nitrile
- Includes Valve
- No
- Temp. Range
- -4 Degrees to 212 Degrees F
- Includes
- (4) Locking Balls
- For Hose I.D.
- 3/8 in
- Valve Type
- Aerodynamic
- Barbed
- Yes
- Max. Working Pressure @ 70 F
- 300 psi
Description
The PARKER - 25SFTF10SXZ is intended for connecting compatible plugs to form sealed fluid connections (seal performance depends on system conditions and proper installation). It features a hose barb connection with a 3/8 in barb size for use with hoses having the specified inner diameter. Constructed of steel with a zinc-plated finish, this coupling supports push-to-connect installation and spring-loaded release sleeve disconnection without external tools. It supports a maximum flow rate of 110 scfm within a temperature range of -4°F to 212°F.
Key Features:
- Hose connection type: Hose Barb with a barb size of 3/8 in and hose fitting size of 3/8 in
- Material: Steel body with a zinc-plated finish
- Seal material: Nitrile
- Coupling locking mechanism: Ball type
- Overall length: 1.69 in (1 11/16 in)
- Max flow rate: 110 scfm
- Temperature range: -4°F to 212°F
- Includes four locking balls
- Valve type: Aerodynamic
- Interchange type: European High Flow
- Hose fitting gender: Male
