Tubing, 1/8 in ID, PFA, Natural, 50 ft.
- Mfr # 104-0188031-NT-50
- Zoro # G1723452
product price:Â
$
106.99
/ea
Free Shipping & Returns
Key Features
Tube Material
Perfluoroalkoxy
Tube Hardness
Shore D: 50 to 60
Inside Dia.
1/8 in
Outside Dia.
3/16 in
Wall Thickness
0.031 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 104-0188031-NT-50
- Zoro #
- G1723452
- UPC #
- -
- Country of Origin
- United States
- Tube Material
- Perfluoroalkoxy
- Tube Hardness
- Shore D: 50 to 60
- Tube Color
- Natural
- Temp. Range
- -450 Degrees to 500 Degrees F
- Max. Working Pressure @ 73 F
- 320 psi
- Max. Working Pressure @ 70 F
- 320 psi
- Item
- Tubing
- Burst Pressure
- 1,280 psi
- Standards
- 21 CFR 177.1550, ASTM D3307, UL 94 V-0 Compliant, USP Class VI
- Material
- PFA
- Color
- Beige
- Application
- Air, Beverage, Chemical, Food
- Hardness
- Shore D 55
- Maximum Operating Temperature
- 500 Degrees F
- Minimum Operating Temperature
- -100 Degrees F
- Weight per Foot
- 0.014 lb/ft
- Resistance Properties
- Heat Resistant
- Clarity
- Semi-Clear
- Features
- Chemically Inert, Low Coefficient of Friction, Low permeability, Non Leaching, Non-Wetting, Self-Extinguishing
- System of Measurement
- Inch
- Vacuum Rated
- Vacuum Rated
- Maximum Operating Pressure
- 320 psi @ 73 Degrees F
- For Environment
- High Temperature
- Maximum Vacuum Pressure
- 28 in Hg
Description
Tubing, Application Air, Beverage, Chemical, Food, Color Beige, Hardness Shore D 55, Inside Diameter 1/8 in, Material PFA, Maximum Operating Pressure 320 psi @ 73 Degrees F, Maximum Operating Temperature 500 Degrees F, Maximum Vacuum Pressure 28 in Hg, Outside Diameter 3/16 in, Overall Length 50 ft, PEX Type Not Applicable, Resistance Properties Heat Resistant, Standards 21 CFR 177.1550, ASTM D3307, UL 94 V-0 Compliant, USP Class VI, Wall Thickness 0.031 in, Bend Radius 5/8 in
