Panel indicator for voltage monitoring, supports 0-10 V input with bright digital display
Mfr # PCE-DPD-P1
Zoro # G922432320
product price: $365.99
/ea
Free Shipping & Returns
Key Features
For Use With
Display for piece counting, speed measurements, etc
Flow Sensors
Fast: max. 500 kHz, Slow: 1 mHz to 200 Hz
Protection Class
Front: IP 65
Entrance
2 counter inputs (NPN / PNP), 1 control signal (reset) counter
Length
3.78 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- PCE-DPD-P1
- Zoro #
- G922432320
- UPC #
- -
- Country of Origin
- Spain
Dimensions
- Length
- 3.78 in
- Dimensions
- 96 x 48 x 91 mm / 3.78 x 1.89 x 3.58 in
- Width
- 1.89 in
Details
- For Use With
- Display for piece counting, speed measurements, etc
- Flow Sensors
- Fast: max. 500 kHz, Slow: 1 mHz to 200 Hz
- Protection Class
- Front: IP 65
- Entrance
- 2 counter inputs (NPN / PNP), 1 control signal (reset) counter
- Power Consumption
- 70 mA
- Measuring Ranges
- Fast: max. 250 kHz, Normal: max. 9 kHz
- Special Features
- 2 counting inputs, 1 reset input, 6digit LED display, 14 mm digit height, Optional output cards, Modeldependent power supply
- Includes
- 1 x Unit sticker, 1 x User manual
- Ambient Temp. Range
- In operation: -25°C to 55°C / -13 to 131°F, Storage: -33°C to 70°C / -27.4 to 158°F
- Supply Voltage
- 85 to 265 V AC / DC (PCE-DPD-P1)
- Application
- Display for piece counting, speed measurements, etc
- Control Panel Cutout
- 92 x 45 mm / 3.6 x 1.8 in (according to DIN)
Description
The panel-mounted display has two pulse inputs (NPN/PNP) and a reset input. The industrial counter displays measured values between -199,999 and 999,999 on the 6-digit LED display. The display on the panel-mounted display can be adjusted using the three front buttons, and the input can be individually scaled. The panel-mounted display can evaluate NPN, PNP, and Namur sensors, as well as rotary encoders and proximity sensors, and thanks to its configuration options, it is suitable for piece counting, speed measurements, etc. The industrial counter measures 96 x 48 mm / 3.8 x 1.9 in. The panel-mounted display offers several counting modes (addition, subtraction, blocking, quadrature, etc.). Up to three different output cards can be optionally installed on the rear of the industrial counter.
