Pic Gauges Industrial Pressure Gauge, 0 to 300 psi, 1 1/2 in Dial, 1/8 in BSPT, Center Back Location SEP-102D-158H-BSPT - main

Industrial Pressure Gauge, 0 to 300 psi, 1 1/2 in Dial, 1/8 in BSPT, Center Back Location

  • Mfr # SEP-102D-158H-BSPT

  • Zoro # G7286476

product price:  $4.59
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Size
1/8 in
Process Connection Type
BSPT
Dial Size (In.)
1 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
SEP-102D-158H-BSPT
Zoro #
G7286476
UPC #
-
Country of Origin
China

Dimensions

Process Connection Size
1/8 in
Dial Size (In.)
1 1/2 in
Manufacturer Warranty Length
1 yr
Nominal Dial Size
1 1/2 in
Case Diameter
2.11 in
Case Depth
1.06 in
Nominal Dial Diameter
1 1/2 in

Details

Item
Industrial Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Type
BSPT
Application
Commercial
Gauge Case Material
Steel
Series
SEP 100
Lens Material
Plastic
Primary Pressure Range
0 to 300
Primary Scale Units
psi
IP/NEMA Rating
Not Rated
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
No
Socket Material
Copper Alloy
Includes
Plastic Case
Gauge Primary Range Smallest Graduation
50
Gauge Application
General-Purpose Case
Calibration Certificate Included
No
Gauge Secondary Range Values
0 to 20
Case Material
Steel
Graduations
50 psi
Gauge Primary Range Numbered Graduations
50
Case Color
Black
Connection Type
BSPT
Standards
ASME
Dial Color
White
Non-Sparking
No
Secondary Pressure Range
0 to 21
Gauge Case Liquid
None
Dry Dampening Feature
None
Removable Bezel
No
Vibration Resistance
None
Cleaned for Oxygen Service
No
Secondary Scale Units
bar
Accuracy Scale
Mid-Scale
Primary Scale Numeric Increments
50
Accuracy Grade
ASME B40.100 Grade B
Pointer Material
Aluminum
Process Connection Gender
Male
Field Fillable
No
Scale Type
Dual
Includes Mounting Hardware
No
Primary Scale Minor Graduations
50
Pressure Range Type
Pressure
Freeze Resistant Movement
No
Pointer Color
Black
Sensor Material
Copper Alloy
Ambient Operating Temperature Range
-40 Degrees to 140 Degrees F
Includes Calibration Certificate
No
Pressure Gauge Type
Industrial Pressure Gauge
Includes Vent Plug
No
Operating Temperature Range
-50 Degrees to 160 Degrees F
Operating Temperature - Minimum
-40 Degrees F
Secondary Scale Vacuum Measurement - Minimum
0 bar
Process Media Temperature - Minimum
-40 Degrees F
NEMA Enclosure Rating
No Enclosure
Operating Temperature - Maximum
140 Degrees F
Primary Scale Vacuum Measurement - Minimum
0 psi
Process Media Temperature - Maximum
140 Degrees F
Case Liquid
None
Primary Scale Pressure Measurement - Minimum
0 psi
Secondary Scale Pressure Measurement - Maximum
21 bar
Secondary Scale Vacuum Measurement - Maximum
20 bar
Primary Scale Pressure Measurement - Maximum
300 psi
Secondary Scale Pressure Measurement - Minimum
0 bar
Compatible with Series
SEP 100
Compatible with Brand
Universal
Primary Scale Vacuum Measurement - Maximum
300 psi

Description

Industrial Pressure Gauge, Nominal Dial Size 1 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material Steel, Process Connection Type BSPT, Process Connection Gender Male, Lens Material Plastic, Process Connection Size 1/8 in, Field Fillable No, Process Connection Location Center Back, Case Color Black, IP/NEMA Rating Not Rated, Primary Pressure Range 0 to 300, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Industrial Pressure Gauge
