Test Lead Wire, CAT III, IEC61010-031, 50 ft., Black
Mfr # 6733-0
Zoro # G3141232
product price:Â $39.99
/eaKey Features
Instrument Safety Rating
CAT III, IEC61010-031
Length
50 ft.
Color
Black
Temperature Range
-58 Degrees to 302 Degrees F
Features
Heat-Resistant Silicone or PVC Insulation, Very Flexible with 192 Strands of 41 AWG Base Copper Conductor
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
- MFR #
- 6733-0
- Zoro #
- G3141232
- UPC #
- 095969296717
- Country of Origin
- Taiwan, Province of China
Dimensions
- Length
- 50 ft.
- Nominal Outside Dia.
- 0.144 in
- Roll Length
- 50 ft
- Wire Size
- 18 AWG
- Nominal Outside Diameter
- 0.144 in
Details
- Item
- Test Lead Wire
- Instrument Safety Rating
- CAT III, IEC61010-031
- Color
- Black
- Temperature Range
- -58 Degrees to 302 Degrees F
- Features
- Heat-Resistant Silicone or PVC Insulation, Very Flexible with 192 Strands of 41 AWG Base Copper Conductor
- Voltage Rating
- 10,000 V DC
- Wire Gauge
- 18 AWG
- Stranding
- 65 AWG/36 Tinned Copper Conductor
- Insulation
- Silicone
- Max. Amps
- 20 A
- Temp. Rating
- -58 to 302 Degrees F (-50 to 150 Degrees C)
- Standards
- IEC 61010-031
- Minimum Temperature Measurement
- -58 Degrees F
- Insulation Material
- Silicone
- Maximum Operating Temperature
- 302 Degrees F
- Maximum Voltage
- 10,000 V
- Maximum Temperature Measurement
- 302 Degrees F
- Maximum Current
- 20 A
Description
Test Lead Wire, Roll Length 50 ft, Color Black, Instrument Safety Rating CAT III, IEC61010-031, Insulation Material Silicone, Nominal Outside Diameter 0.144 in, Stranding 65 AWG/36 Tinned Copper Conductor, Wire Size 18 AWG, Maximum Voltage 10,000 V, Minimum Temperature Measurement -58 Degrees F, Maximum Temperature Measurement 302 Degrees F, Maximum Current 20 A, Maximum Operating Temperature 302 Degrees F, Standards IEC 61010-031
