Techtron PPS HPV Sheet (Q), 0.500 Thick, 24 X 39.4
Mfr # SPPSHPV.500Q-24X39.4
Zoro # G500913159
product price:Â $5,212.99
/ea
Free Shipping & Returns
Key Features
Width
24
Height
0.5
Length
39.4
Material
Techtron
Weight
26
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- SPPSHPV.500Q-24X39.4
- Zoro #
- G500913159
- UPC #
- -
- Country of Origin
- Multiple
Dimensions
- Width
- 24
- Height
- 0.5
- Length
- 39.4
Details
- Material
- Techtron
- Weight
- 26
- Dielectric Strength (volts/mil)
- 500
- UL94 Flammability Rating Method: UL 94
- V-0
- Specific Gravity (73 Deg: g/cm3)
- 1.43
- Flexural Strength (psi @ 73 Deg: F)
- 10500
- Tensile Strength (psi @ 73 Deg;)
- 10900
- Heat Deflection Temp. (264 psi) Deg:F
- 240
- Max. Recommended Use Temp (Deg:F)
- 430
- CoLT Expansion (x 10-5 in./in./Deg:F)
- 0.33
- Tensile Elongation at Break (% @ 73 Deg: F)
- 5
- Thermal Conductivity (BTU-in/ft²-hr-°F)
- 2.1
Description
Techtron HPV is an extruded form of polyphenylene sulfide with reinforcement and internal lubricants, offering excellent wear resistance, strength, dimensional stability and chemical resistance. Techtron HPV is an ideal material for applications where standard engineering plastics (nylon, acetal, and polyesters) fall short, and advanced materials (polyimides, PEEK, and polyamide-imides) are over-engineered solutions. Note: Rods are sold in Standard 1 meter lengths (3.28 feet) (39.3 inches)
