  11. Cord Connector, Silver, 2-9/16" L, Straight
Raco Cord Connector, Silver, 2-9/16" L, Straight 3745-0 - main

Cord Connector, Silver, 2-9/16" L, Straight

  • Mfr # 3745-0

  • Zoro # G5490801

product price: $10.19
/ea

Key Features

Hub Size
1/2 in MNPT
Material
Iron
Color
Silver
Length
2-9/16"
Standards
cULus
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
3745-0
Zoro #
G5490801
UPC #
050169983423
Country of Origin
China

Dimensions

Hub Size
1/2 in MNPT
Length
2-9/16"
Length - External Strain Relief
No External Strain Relief
Cord Dia. Range
0.15 in to 0.25 in
Conduit Size
1/2"
Length - Box to End of Connector
2 9/16 in
Thread Size
0.5 in
Compatible Conduit Trade Size
1/2 in
Width
1.250 in
Each - Width
1.250 in
Dimensions
2.56 in x 1.25 in x 1.25 in
Trade Size
0.5 in
Size
2.56 in x 1.25 in x 1.25 in
Height
1.25 in

Details

Item
Enhanced Rating Cord Connector
Material
Iron
Color
Silver
Standards
cULus
Number of Cords
1
Material - External Strain Relief
No External Strain Relief
Connector Type
Straight
Box Connection
1/2 in MNPT
Body Color - Cord Connector
Silver
Item - Cord Connector
Enhanced Rating Cord Connector
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Strain Relief Type
No External Strain Relief
Material - Cord Connector
Malleable Iron
Style - Connector
45 Degrees
Gland Color Code
Red
Insulated
No
Grommet Material
Neoprene
Grommet Color Code
Red
Body Color
Silver
NEMA Rating
NEMA 4
For Maximum Cable OD
0.25 in
Connection Orientation
45 Degrees
Liquid Tight
Yes
Thread Type
NPT Thread
Body Material
Iron
For Minimum Cable OD
0.15 in
Collar Material
Iron
Cable Range
.15 - .25 in
Certified Listed
cULus Listed
Standard
cULus Listed
Application
For use in wet or dry locations to provide a liquidtight and strain relief termination for flexible cord and cable;RACO liquidtight strain relief cord connectors are suitable for use in Class I, Div. 2; Class II, Div. 1 & 2; and Class III, Div. 1 & 2 hazardous locations
Features
Malleable iron construction provides mechanical strength and durability; Neoprene grommets are color-coded by cable diameter allowing for quick and easy identification; Metallic components are zinc plated for corrosion protection; Unique grommet design is forced up and around the cord when the nut is tightened creating a liquidtight seal; Time saving and easy installation - no need to disassemble the fitting for cord installation; Additional colors and sizes available

Description

Enhanced Rating Cord Connector, Cord Dia. Range 0.15 in to 0.25 in, Box Connection 1/2 in MNPT, Material - Cord Connector Malleable Iron, External Strain Relief Material No External Strain Relief, Gland Color Code Red, Body Color - Cord Connector Silver, Number of Cords 1, Style - Connector 45 Degrees , Strain Relief Type No External Strain Relief, Length - Box to End of Connector 2 9/16 in, Insulated No, Standards cULus
