  9. Counter, 2 Line Red/Green Backlight LCD
Red Lion Controls Counter, 2 Line Red/Green Backlight LCD C48CD005 - main

Counter, 2 Line Red/Green Backlight LCD

  • Mfr # C48CD005

  • Zoro # G104104717

product price: $437.99
/ea
Free Shipping & Returns

Key Features

Mounting
Panel
Reset Type
Key
Display
2 Line Red/Green Backlight LCD
Number of Digits
6
Diameter
4 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
C48CD005
Zoro #
G104104717
UPC #
-
Country of Origin
United States

Dimensions

Diameter
4 in
Depth
4.54 in
Height
1.95 in
Character Height
0.2 in Secondary, 0.3 in Main
Manufacturers Warranty Length
Limited
Width
1.95 in
Dimension
1.95 in. W x 1.95 in. H x 4.17 in. D
Cutout DIN Size
1/8
Cutout Height
1 7/8 in
Overall Height
2 in
Cutout Width
1 7/8 in
Overall Width
2 in
Overall Depth
4 5/8 in
Digit Height - Maximum
0.3 in

Details

Item
Counter
Mounting
Panel
Reset Type
Key
Display
2 Line Red/Green Backlight LCD
Number of Digits
6
Output Rating
1/10 HP @ 120V AC, 5 A @ 250V AC, 5 A @ 30V DC
Special Features
Bi-Directional and Quadrature Counting, Red Top Line and Green Bottom Line Display
Fits
1/16 DIN; 1.772 in x 1.772 in Panel Cutout
Output
(2) NPN Open Collector
Scaler
Yes
Prescaling Range
0.00001 to 9.99999
NEMA Rating
4X
Interface
RS-485
Power Required
11 to 14 V DC, 85 to 250 V AC
Input Signal
1.5V DC Current Sinking, 30V DC Current Sourcing
Min. On/Off Pulse
10 msec
Preset
2
IP Rating
IP65
Connector Type
Wire Clamp/Screw Terminal
Input Voltage
85 to 250V AC
Standards
cRUus, UKCA, UL E137808
Counter Type
Electronic Preset Counter
Count - max
9.99999
Application
Bi-directional, Dual Preset, Count-Up/Down, Quadrature
Operator
Nonvolatile EEPROM
Reset
External, Front Panel, Programmable
Speed
11 kHz (Max)
Voltage
85-250V AC
Digits
7 Segment, (2) Line, (6) 7.62 mm H, (6) 5.08 mm H - Reflective LCD
Connection
Screw Terminals
NEMA Enclosure Rating
4X
Digit Color
Green/Yellow
Terminal Connection Type
Wire Clamping Screw
Counter Display Type
LCD
Output Type
NPN Open Collector, PNP Open Collector, Relay
Features
Isolated High Voltage Input, Reflective Display
Mounting Style
DIN Track

Description

Counter, Number of Digits 6, 2 Line Red/Green Backlight LCD Display, Character Height 0.2 in Secondary, 0.3 in Main, Input Signal 1.5V DC Current Sinking, 30V DC Current Sourcing, Output Rating 1/10 HP @ 120V AC, 5 A @ 250V AC, 5 A @ 30V DC, Output (2) NPN Open Collector, Mounting Panel, Diameter 4 in, Height 1.95 in, Depth 4.54 in, Width 1.95 in, Scaler Yes, Preset 2, Power Required 11 to 14 V DC, 85 to 250 V AC, Min. On/Off Pulse 10 msec, Prescaling Range 0.00001 to 9.99999, Reset Type Key
