  5. Pressure Gauge, 0 to 60 psi, 2 1/2 in Dial, 1 1/2 in Tri-Clamp, Bottom Location
Reotemp Pressure Gauge, 0 to 60 psi, 2 1/2 in Dial, 1 1/2 in Tri-Clamp, Bottom Location SG25ATC15P17 - main

Pressure Gauge, 0 to 60 psi, 2 1/2 in Dial, 1 1/2 in Tri-Clamp, Bottom Location

  • Mfr # SG25ATC15P17

  • Zoro # G3971021

product price:  $285.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-2.00%
Process Connection Location
Bottom
Process Connection Size
1 1/2 in
Process Connection Type
Tri-Clamp
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
SG25ATC15P17
Zoro #
G3971021
UPC #
-
Country of Origin
United States

Dimensions

Process Connection Size
1 1/2 in
Dial Size (In.)
2 1/2 in
Case Diameter
2.68 in
Nominal Dial Size
2 1/2 in
Nominal Dial Diameter
2 1/2 in

Details

Item
Pressure Gauge
Accuracy
+/-2.00%
Process Connection Location
Bottom
Process Connection Type
Tri-Clamp
Application
Beverage, Biotechnology, Food Processing Industry, Pharmaceutical
Gauge Case Material
304 Stainless Steel
Series
SG
Lens Material
Plastic
Primary Pressure Range
0 to 60
Primary Scale Units
psi
IP/NEMA Rating
IP65, NEMA 4X
Liquid-Filled Case
Yes
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
No
Gauge Filled With
Glycerin
Calibration Certificate Included
No
Case Color
Metallic
Gauge Application
Sanitary
Socket Material
316L Stainless Steel
Case Material
304 Stainless Steel
Wetted Materials
Stainless Steel
Connection Type
Triclamp
Standards
3A Sanitary Standard
Sensor Material
316 Stainless Steel
Cleaned for Oxygen Service
No
Adjustable Pointer
No
Compatible Process Media
Beverage, Dairy, Food, Pharmaceutical
Pressure Gauge Type
Sanitary Pressure Gauge
Includes Calibration Certificate
No
Dial Color
White
Includes Vent Plug
No
Vibration Resistance
Liquid-Filled
Gauge Case Liquid
Glycerin
Pressure Range Type
Pressure
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F
Freeze Resistant Movement
No
Dial Face Material
Aluminum
Field Fillable
Yes
Process Temperature Range
-40 Degrees to 400 Degrees F
Dry Dampening Feature
None
Removable Bezel
No
Maximum Pressure
60
Primary Scale Pressure Measurement - Minimum
0 psi
Process Media Temperature - Minimum
-40 Degrees F
NEMA Enclosure Rating
4X
Process Media Temperature - Maximum
400 Degrees F
IP Rating
IP65
Case Liquid
Glycerin
Resistance Properties
Corrosion Resistant, Dust Resistant, Water Resistant, Wind Resistant
Primary Scale Pressure Measurement - Maximum
60 psi
Operating Temperature - Maximum
150 Degrees F
Operating Temperature - Minimum
-40 Degrees F

Description

Pressure Gauge, Gauge Type Sanitary, Dial Size 2 1/2 In., Range 0 to 60 psi, Connection Size 1-1/2 In., Connection Location Triclamp Connection
