Spring plunger

The SCHMALZ - 10.01.02.00568 is a vacuum buffer designed for pneumatic systems. It functions as a small reservoir that stores and stabilizes vacuum pressure by absorbing pressure spikes and smoothing flow during intermittent or pulsed vacuum demand. This component is designed to protect pumps and valves, damps pressure spikes to stabilize flow during intermittent or pulsed vacuum demand, and is designed to maintain suction within specified operating conditions. The buffer features a rotating design to accommodate swivel or rotary motion during operation, contributing to adaptability in various setups within pneumatic vacuum systems.

Key Features:

• Series: FSTE, indicating its product line designation.
• Rotating buffer rotation allowing for swivel motion.
• External mounting with M20 screws and a thread pitch of 1.5 mm.
• Hex sizes of 17 mm and 24 mm for tools used in assembly or maintenance.
• Pad end port is male, sized at 1/4 in with G thread type.
• Vacuum end port is female, sized at 1/8 in.
• Operating temperature range from 0 Degrees C to a maximum of 80 Degrees C.
• Physical dimensions include an outside diameter of 20 mm and an overall length of 124 mm.
• Spring force of 12.7 N with a spring rate of 0.45 N/mm and a stroke length of 50 mm.
• Weight of the unit is 175 g.
