Schneider Electric DIN Rail & Top Flange, Enclosed Power Relay, 30 A, 4 Pins, Screw 725AXXSC3ML-12D - main

DIN Rail & Top Flange, Enclosed Power Relay, 30 A, 4 Pins, Screw

  • Mfr # 725AXXSC3ML-12D

  • Zoro # G1508455

product price:  $12.75
/ea

Key Features

Mounting Style
DIN Rail & Top Flange
Electrical Connection
Screw
Number of Pins
4
Coil Voltage
12V DC
Current Rating
30 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
725AXXSC3ML-12D
Zoro #
G1508455
UPC #
-
Country of Origin
China

Dimensions

Dimensions
2.09"H, 2.67"W, 1.30"D
Overall Height - Relay
2.09 in
Overall Depth
2.12 in
Body Width
2.67 in
Body Depth
1.3 in
Body Height
1.3 in
Depth
2.12 in (53.9 mm)
Width
1.37 in (34.9 mm)

Details

Item
Enclosed Power Relay
Mounting Style
DIN Rail & Top Flange
Electrical Connection
Screw
Number of Pins
4
Coil Voltage
12V DC
Current Rating
30 A
Contact Form
SPST-NO
Contact Rating (AC)
30 A @ 240/277V
Contact Rating (DC)
30 A @ 28/30V
Number of Poles
1
Contact Amp Rating (Resistive)
30A @ 277VAC/30VDC
Standards
CE Certified, CSA Certified, IEC 60947-1, UL60947-4-1A
Contact Material
Silver Alloy
Coil Rating
2.5VA, 1.9W
Power Consumption - Relay
2.5 W
Features
3hp @ 277V AC, LED & Button
Hz
50/60
Series
Harmony(TM) 725 Power Series
Response Time
30 msec
Motor Rated
Yes
Maximum Switching Voltage
240V, 277V
Frequency
50/60 Hz
Maximum Operating Temperature
131 Degrees F
IP Rating
IP20
Horsepower @ 240V AC
3 hp
Push-To-Test Method
Test Button
Minimum Switching Current
100 mA
Coil Resistance
75 ohm
Dielectric Strength
4,000V AC Between Coil and Contact
Mechanical Operating Durability
5,000,000
Operating Current
30 A at 240V AC (General Purpose), 30 A at 240V AC (Resistive Load), 30 A at 277V AC (Resistive Load), 30 A at 28V DC (Resistive Load), 30 A at 30V DC (Resistive Load)
Status Indicator
LED Indicator
Electrical Operating Durability
100,000
Minimum Operating Temperature
-4 Degrees F
Weight
4.23 oz
Power Consumption
1.9 W
Horsepower @ 120V AC
1 1/2 hp
Input Voltage
9.6 to 13.2V DC
Product Range
Harmony Electromechanical Relays
Series name
Power
Contact Composition
1 NO
Rated power in W
1.5 kW 120 V tungsten
Average Coil Consumption
1.90 W
Connections - terminals
Screw coil terminal M3.5; Screw contact terminal M4
Ambient Air Temperature for Storage
-67 to 212°F (-55 to 100°C)
Rated Power in HP
3 hp 277 V AC; 1.5 hp 120 V AC
Tightening Torque
10.6...15 lb.in; 1.2...1.7 N.m
Nominal input voltage
9.6...13.2 V DC
ambient temperature range - operational
-4 to 131°F (-20 to 55°C)
Product Certifications
UL; CSA; CE

Description

Enclosed Power Relay, Coil Voltage 12V DC, Contact Form SPST-NO, Current Rating 30 A, Electrical Connection Screw Terminal, Number of Pins 4, Status Indicator LED Indicator, Contact Rating (AC) 30 A @ 240/277V, Contact Rating (DC) 30 A @ 28/30V, Horsepower @ 120V AC 1 1/2 hp, Horsepower @ 240V AC 3 hp, Mounting Style DIN Rail & Top Flange, Push-To-Test Method Test Button, Body Depth 1.3 in, Body Height 1.3 in, Body Width 2.67 in, Coil Resistance 75 ohm, Contact Material Silver Alloy
