IEC Magnetic Contactor, 1NC, 480V AC, 3 P, Non-Reversing, Screw Clamp

  • Mfr # LC1K0901T7
  • Zoro # G210080929
product price:
$
81.49
/ea

Key Features

Auxiliary Contact Form
1NC
Coil Voltage
480V AC
Number of Poles
3
Full Load Amps-Inductive
9 A
Full Load Amps-Resistive
20 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LC1K0901T7
Zoro #
G210080929
UPC #
3389118014725
Country of Origin
France

Dimensions

Overall Height
2.28 in
Overall Width
1.77 in
Overall Depth
2.24 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NC
Coil Voltage
480V AC
Number of Poles
3
Full Load Amps-Inductive
9 A
Full Load Amps-Resistive
20 A
Reversing Capability
Non-Reversing
Terminal Connection Type
Screw Clamp
Number of Auxillary Contacts
1
Standards
CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, GB/T 14048.4, JIS C8201-4-1, UL 60947-4-1
Series
TeSys K
IP Rating
IP20
Contactor Style
IEC
Frequency
50/60 Hz
Includes Auxiliary Contacts
Yes
Resistance Properties
Insulation Resistant
Embedded Surge Suppressor
No
Mechanical Operating Durability
10,000,000
Electrical Operating Durability
1,300,000 (AC-3), 1,300,000 (AC-3e), 160,000 (AC-1), 20,000 (AC-4)
Maximum Voltage Rating
480V AC
Full Load Current - Resistive
20 A
Mounting Style
DIN Rail, Plate
Full Load Current - Inductive
9 A

Description

Schneider Electric’s IEC Magnetic Contactor is a 3-pole, non-reversing electric switching device rated for operation within specified parameters. It features a 480V AC coil and screw clamp terminals, with one normally closed auxiliary contact (1NC). The unit is part of the TeSys K series and is compatible with DIN rail or plate mounting; IP20 is the specified ingress protection rating.

Key features:

  • Item: IEC Magnetic Contactor; Series: TeLis K; Reversing Capability: Non-Reversing
  • Poles: 3; Auxiliary contacts: 1NC; Includes auxiliary contacts: Yes; Auxiliary contact form: 1NC
  • Coil voltage: 480V AC; Maximum voltage rating: 480V AC; Frequency: 50/60 Hz
  • Terminal connection: Screw Clamp; Mounting style: DIN Rail, Plate
  • IP rating: IP20
  • Full Load Amps: rated for use at indicated current levels under specified conditions
  • Electrical operating durability: tested for a number of operational cycles under standard test conditions
  • Mechanical operating durability: 10,000,000 cycles
  • Insulation resistance: measured according to applicable standards
  • Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, GB/T 14048.4, JIS C8201-4-1, UL 60947-4-1
  • Dimensions: Depth 2.24 in; Height 2.28 in; Width 1.77 in
  • Embedded surge suppressor: No
