  13. IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type
Schneider Electric IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type LC1G800EHEN - main

IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type

  • Mfr # LC1G800EHEN

  • Zoro # G410190343

product price: $4,571.99
/ea
Free Shipping & Returns

Key Features

Auxiliary Contact Form
1NC/1NO
Coil Voltage
48V-130V AC/DC
Number of Poles
3
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LC1G800EHEN
Zoro #
G410190343
UPC #
3606481921918
Country of Origin
China

Dimensions

Overall Width
8.31 in
Overall Depth
10.47 in
Overall Height
11.18 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NC/1NO
Coil Voltage
48V-130V AC/DC
Number of Poles
3
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
Standards
CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
IP Rating
IP20
Series
TeSys Giga
Includes Auxiliary Contacts
Yes
Embedded Surge Suppressor
No
Minimum Operating Temperature
-13 Degrees F
Phase
Single
Frequency
50/60 Hz
Mechanical Operating Durability
5,000,000
Mounting Style
Plate
Maximum Operating Temperature
140 Degrees F
Contactor Style
IEC
Maximum Voltage Rating
1000V AC
Full Load Current - Resistive
1,050 A
Full Load Current - Inductive
800 A

Description

The Schneider Electric IEC Magnetic Contactor is a 3-pole, coil-driven switch rated for use in IEC-based control systems. It is rated for coil voltages between 48V and 130V (AC/DC) and includes auxiliary contacts with standard configurations. The unit is plate-mounted with spring-type terminal connections within specified parameters, part of the TeSys Giga series, and rated for operation within specified voltage and frequency ranges.

Item: IEC Magnetic Contactor

  • Series: TeSys Giga
  • Contactor style: IEC
  • Phase: Single
  • Number of poles: 3
  • Auxiliary contacts: 2 (1NC/1NO)
  • Coil voltage: 48V-130V AC/DC
  • Terminal connection type: Spring Type
  • Mounting style: Plate
  • Frequency: 50/60 Hz
  • Maximum voltage rating: 1000V AC
  • IP rating: Conforms to IP20 ingress protection standards
  • Minimum operating temperature: suitable for environments within the specified temperature range (-13°F and above)
  • Maximum operating temperature: suitable for environments within the specified temperature range (up to 140°F)
  • Mechanical operating durability: 5,000,000 cycles
  • Overall dimensions: Depth 10.47 in, Height 11.18 in, Width 8.31 in
  • Embedded surge suppressor: No
  • Includes auxiliary contacts: Yes
  • Full Load Amps – Inductive: 900 A
  • Full Load Amps – Resistive: 1,050 A
  • Full Load Current – Inductive: 800 A
  • Full Load Current – Resistive: 1,050 A
  • Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
