  7. IEC Magnetic Contactor, 1NO, 48V AC, 3 P, Non-Reversing, Screw Clamp
Schneider Electric IEC Magnetic Contactor, 1NO, 48V AC, 3 P, Non-Reversing, Screw Clamp LC1K1210E7 - main

IEC Magnetic Contactor, 1NO, 48V AC, 3 P, Non-Reversing, Screw Clamp

  • Mfr # LC1K1210E7

  • Zoro # G110070563

product price:  $94.29
/ea
Free Shipping & Returns

Key Features

Auxiliary Contact Form
1NO
Coil Voltage
48V AC
Number of Poles
3
Reversing Capability
Non-Reversing
Terminal Connection Type
Screw Clamp
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LC1K1210E7
Zoro #
G110070563
UPC #
3389110346176
Country of Origin
France

Dimensions

Overall Height
2.28 in
Overall Depth
2.24 in
Overall Width
1.77 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NO
Coil Voltage
48V AC
Number of Poles
3
Reversing Capability
Non-Reversing
Terminal Connection Type
Screw Clamp
Number of Auxillary Contacts
1
Standards
CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, GB/T 14048.4, JIS C8201-4-1, UL 60947-4-1
Series
TeSys K
IP Rating
IP20
Frequency
50/60 Hz
Mechanical Operating Durability
10,000,000
Resistance Properties
Insulation Resistant
Maximum Voltage Rating
690V AC
Embedded Surge Suppressor
No
Mounting Style
DIN Rail, Plate
Contactor Style
IEC
Electrical Operating Durability
1,300,000 (AC-3), 1,300,000 (AC-3e), 300,000 (AC-1)
Includes Auxiliary Contacts
Yes
Full Load Current - Inductive
12:00 AM
Full Load Current - Resistive
20 A

Description

The SCHNEIDER ELECTRIC - IEC Magnetic Contactor is a non-reversing, three-pole device with an auxiliary contact form of 1NO. It operates on a coil voltage of 48V AC and has a maximum voltage rating of 690V AC. The contactor is designed for DIN Rail or Plate mounting styles and features insulation resistance properties. With its compact dimensions (2.24 in depth, 2.28 in height, and 1.77 in width), it fits comfortably within various industrial settings.

Key Features:

  • Operates at frequencies of 50/60 Hz.
  • Has full load amps-inductive of 12 A and full load amps-resistive of 20 A.
  • Includes one auxiliary contact.
  • Rated as IP20, indicating its ability to resist ingress of solid objects up to 12mm; it does not have a rating for water resistance.
  • Mechanical operating durability is tested up to ten million cycles and electrical operating durability has been tested within the range of 300,000 (AC-1) to over a million (AC-3 & AC-3e).
  • Complies with multiple standards including CSA C22.2 No 60947-4-1, EN/IEC 60947-4-, GB/T14048.4 JIS C8201 -4 -1 UL60947 -4 -1
  • -The terminal connection type is Screw Clamp250 which is designed for connecting wires and devices.
