- Relative Humidity
- 95-95 % without condensation
- Current State 0 Guaranteed
- <= 1.2 mA
- Discrete Input Voltage
- 24 V DC
- Product Or Component Type
- discrete solid state I/O base DC
- Voltage State 1 Guaranteed
- 11 to 30 V
- Protective Treatment
- TC
- Peak Output Current
- 2.8 A
- Fault Type
- short circuit on output || overload on output
- Discrete Output Voltage
- <= 30 V DC || 24 V DC
- Operating Altitude
- <= 16404.2 ft (5000 m)
- Resistance To Electrostatic Discharge
- 4 kV contact IEC 801-2 || 8 kV on air IEC 801-2
- Ambient Air Temperature For Storage
- -40-85°C
- Product Certifications
- UL || CSA
- Voltage State 0 Guaranteed
- -3 to 5 V
- Terminals Description Plc N°2
- (5)OUT_DIS#5 || (1)OUT_DIS#1 || (2)OUT_DIS#2 || (4)OUT_DIS#4 || (6)OUT_DIS#6 || (8)OUT_DIS#8 || (7)OUT_DIS#7 || (3)OUT_DIS#3 || (1L+)PW_POS || (2L+)PW_POS || TB_1
- Terminals Description Plc N°1
- (11)IN_DIS#11 || (M-)PW_NEG || (L+)PW_POS || (7)IN_DIS#7 || (15)IN_DIS#15 || (16)IN_DIS#16 || (1)IN_DIS#1 || (4)IN_DIS#4 || (6)IN_DIS#6 || (14)IN_DIS#14 || (13)IN_DIS#13 || (5)IN_DIS#5 || TB || (12)IN_DIS#12 || (10)IN_DIS#10 || (8)IN_DIS#8 || (2)IN_DIS#2 || (3)IN_DIS#3 || (9)IN_DIS#9
- Power Dissipation
- 6.5 W || <= 10 W
- Marking
- CE
- Maximum Leakage Current
- 1 mA 24 V output circuit)
- Discrete Output Type
- solid state switch
- Current State 1 Guaranteed
- >= 2.5 mA
- Response Time
- < 0.1 ms from state 0 to state 1 on output || < 0.1 ms from state 1 to state 0 on output || 2.2 ms from state 0 to state 1 on input || 3.3 ms from state 1 to state 0 on input
- Discrete Output Current
- 16 A per module || 2 A per point || 8 A per group
- Group Of Channels
- 4 groups of 4 inputs || 2 groups of 4 outputs
- Input Resistance
- 4 kOhm
- Discrete Output Logic
- positive
- [Us] Rated Supply Voltage
- 24 V DC
- Ambient Air Temperature For Operation
- 0-60°C
- Isolation Between Channels And Bus
- 500 V AC
- Resistance To Electromagnetic Fields
- 10 V/m 80 to 1000 MHz IEC 801-3
- Input Voltage Limits
- 3 to 30 V
- Discrete Output Number
- 8
- Current Consumption
- 250 mA 24 V DC
- Discrete Input Number
- 16 IEC 1131-2 Type 1
- Discrete Input Logic
- positive
