Schneider Electric Pilot Light Complete, LED, Red XB6AV4GB - main

Pilot Light Complete, LED, Red

  • Mfr # XB6AV4GB

  • Zoro # G0105038

product price: $22.59
/ea

Key Features

Voltage
120V AC
Color
Red
Lamp Type
LED
Shape
Round
Terminal Connection
Faston Connector
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XB6AV4GB
Zoro #
G0105038
UPC #
785901433248
Country of Origin
France

Dimensions

Size
16 mm
Width
18 mm
Length
57 mm
Height
18 mm
Mounting Diameter
0.63 in (16 mm)
Depth
2.24 in (57 mm)
Overall Height
0.71 in
Manufacturer Warranty Length
18 mo
Panel Cutout Diameter
16 mm
Overall Depth
2.24 in
Overall Width
0.71 in

Details

Item
Pilot Light
Voltage
120V AC
Color
Red
Lamp Type
LED
Shape
Round
Terminal Connection
Faston Connector
Contact Form
(X1-X2)PL
Lens Material
Plastic
Bezel
Plastic
Lens Type
Smooth
Lamp Module Type
Transformer
Basic Material
Plastic
IP Rating
IP65, IP66, IP67, IP69, IP69K
Body Material
Plastic
Replacement Lamps
4VW69
Lamp Voltage
120V AC
Standards
CCC, CSA, GOST, REACH, RoHS, UL Listed, WEEE
NEMA Rating
1, 12
Type
Steady Signal
Connections - Terminals
Faston connectors 2.8 x 0.5 mm
Surge Withstand
1 kV direct contact IEC 61000-4-5; 2 kV in free air IEC 61000-4-5
Light Block Supply
Direct
Product Certifications
CCC; UL; GOST; CSA
Current Consumption
15 mA
NEMA Degree Of Protection
NEMA 13 UL 50; NEMA 4 UL 50; NEMA 4X UL 50; NEMA 13 CSA C22.2 No 94; NEMA 4 CSA C22.2 No 94; NEMA 4X CSA C22.2 No 94
IP Degree Of Protection
IP65 IEC 60529
Signalling Type
Steady
Rated Impulse Withstand Voltage
4 kV EN/IEC 60947-1
Rated Supply Voltage
48 to 120 V AC
Vibration Resistance
+/- 3 mm 2 to 500 Hz)IEC 60068-2-6; 5 gn 2 to 500 Hz)IEC 60068-2-6
Resistance To Fast Transients
2 kV IEC 61000-4-4
Ambient Air Temperature For Operation
-13 to 158°F (-25 to 70°C)
Rated Insulation Voltage
250 V 2)EN/IEC 60947-1
Shock Resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27; 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Electrical Shock Protection Class
Class II IEC 61140
Resistance To Electrostatic Discharge
6 kV on contact (on metal parts) IEC 61000-4-2; 8 kV in free air (in insulating parts) IEC 61000-4-2
Operating Position
Any position
Protective Treatment
TC
Supply Voltage Limits
6 to 30 V AC/DC
Bulb Base
Integral LED
Ambient Air Temperature For Storage
-40 to 158°F (-40 to 70°C)
Resistance To Electromagnetic Fields
9.14 V/m (10 V/m) IEC 61000-4-3
Product Or Component Type
Complete pilot light
Electromagnetic Emission
Class B EN 55011
Series
XB6
Resistance Properties
Dust Resistant, Impact Resistant, Vibration Resistant, Waterproof
Lens Color
Red
Includes Lens
Lens Included
NEMA Enclosure Rating
13, 4, 4X
Lamp Color
Red
Includes Lamp Module
Lamp Module Included
Includes Push-To-Test
No Push-To-Test Included
Voltage Rating - Maximum
120 V AC
Lamp Voltage - Maximum
120 V AC

Description

Pilot Light, Voltage 120V AC, Color Red, Lamp Type LED, Shape Round, Terminal Connection Faston Connector, Lens Material Plastic, 16 mm, Lamp Module Type Transformer, Basic Material Plastic, Lens Type Smooth, Lamp Voltage 120V AC, Replacement Lamps 4VW69, Body Material Plastic, NEMA Rating 1, 12, IP Rating IP65, IP66, IP67, IP69, IP69K, Standards CCC, CSA, GOST, REACH, RoHS, UL Listed, WEEE
