Pneumatic Tstat, Heat or Cool, 3Pipe, High

Name: Pneumatic Tstat, Heat or Cool, 3Pipe, High
Brand: Schneider Electric
SKU: G2492659
Price: 483.99 USD
Availability: InStock

483.99

/ea

Free Shipping & Returns

For Use With

Pneumatic Devices and Actuators in Environmental Control Systems; Induction Units; Fan Coil Units; Unit Ventilators

Includes

20-818 Mounting Bracket with Screws; Remote Bimetal Sensors

Application

Heat or Cool

Overall Width

2 1/16 in

Temperature Settings

Single Temperature

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Get 10% off your order

Specifications

MFR #: 2298-061
Zoro #: G2492659
UPC #: -
Country of Origin: United States
Item: Thermostat, Unit Vent, 65-85 Degrees F
For Use With: Pneumatic Devices and Actuators in Environmental Control Systems; Induction Units; Fan Coil Units; Unit Ventilators
Includes: 20-818 Mounting Bracket with Screws; Remote Bimetal Sensors
Application: Heat or Cool
Temperature Settings: Single Temperature
Manual Indexing Switch: No
Pneumatic Thermostat Type/Indexing Switch: Remote Reset
Differential Type: Fixed
Minimum Control Temperature: 65 Degrees F
Air Consumption: 29.4 scim
Action: Direct
Maximum Control Temperature: 85 Degrees F
Number of Pipes: 3
Temperature Scale: Fahrenheit
Temperature Control Range: 65 Degrees to 85 Degrees F
Pneumatic Thermostat Type: Remote Reset
Number of Pipes/Air Flow Output: 3 Pipes, High Volume
Temperature Sensitivity: 2.5 psig/ Degrees F
Mounting Direction/Includes Cover: Horizontal/Vertical, Yes
Thermostat Action: Direct
Sensor Location: Remote
Maximum Air Pressure: 30 psig
Sensor Type: Bi-Metallic Spring
Fitting Connection: 1/4 in
Compatible System Type: Pneumatic Valves and Damper Actuators
Air Flow Output: High Volume
Number of Dials: Single
Mounting Direction: Horizontal, Vertical

Pneumatic Thermostat, Air Consumption 29.4 scim, Includes Mounting Bracket, Mounting Hardware
