Socket, General Purpose Relay, Square, 15 A, 5 Pins, Faston Connector

  • Mfr # 781XAXRC-24A

  • Zoro # G0069469

product price:
$
7.45
/ea

Key Features

Mounting Style
Socket
Electrical Connection
Faston Terminal
Base Shape
Square
Number of Pins
5
Coil Voltage
24V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
781XAXRC-24A
Zoro #
G0069469
UPC #
-
Country of Origin
China

Dimensions

Overall Height - Relay
1.37 in
Overall Depth
1.39 in
Body Width
0.53 in
Body Height
1.07 in
Body Depth
1.39 in
Width
0.55 in (14 mm)
Depth
1.07 in (27.3 mm)

Details

Item
General Purpose Relay
Mounting Style
Socket
Electrical Connection
Faston Terminal
Base Shape
Square
Number of Pins
5
Coil Voltage
24V AC
Current Rating
15 A
Contact Form
SPDT
Contact Rating (AC)
10 A @ 151/277V, 15 A @ 120 to 277/120/150/250V (NO), 7.55 A @ 250V (NC)
Contact Rating (DC)
15 A @ 28V (NO), 7.55 A @ 28V (NC)
Contact Material
Gold Flashed Silver Alloy
Socket Code
L
Socket
Mfr. No. 70-781D5R-1A, 70-781D5, 70-781D
Power Consumption - Relay
1.6 VA
Status Indicator
Mechanical Flag
Standards
CE Certified, CSA Certified, UL Listed
Features
Clear Cover
Green Environmental Attribute
RoHS 2011/65/EU Compliant
Series
781R Series
Power Consumption
1.1 W, 1.6 VA
Horsepower @ 120V AC
1/2 hp
Motor Rated
Yes
Minimum Switching Current
10 mA
Resistance Properties
Shock-Resistant, Vibration-Resistant
Input Voltage
24V AC
Operating Current
10 A at 151/277V, 15 A at 120 to 277V, 15 A at 120/150V, 15 A at 250V, 15 A at 28V, 15 A at 28V (NO), 7.55 A at 250V (NC), 7.55 A at 28V (NC)
Dielectric Strength
1,500V AC Between Contacts, 2,000V AC Between Coil and Contact, 2,000V AC Between Poles
Push-To-Test Method
No Button
Maximum Switching Voltage
250V AC, 300V DC
Maximum Operating Temperature
131 Degrees F
Electrical Operating Durability
100,000
Minimum Operating Temperature
-40 Degrees F
Horsepower @ 240V AC
1 hp
Frequency
50/60 Hz
For Use With
Automation Panels and Controls
Weight
0.92 oz
Coil Resistance
177 ohm
Mechanical Operating Durability
10,000,000
Response Time
25 msec
IP Rating
IP40
Operating Time
25 ms; 20 ms
Ambient Air Temperature for Operation
-40 to 131°F (-40 to 55°C)
Contact Composition
1 NC + 1 NO
Product Range
Legacy
Power consumption in W
1.1 W DC
Motor Power HP
0.5 hp 120 V AC 50-60 Hz; 1 hp 277 V AC 50-60 Hz
Vibration Resistance
+/-1 mm 10 to 35 Hz); 3 gn 35 to 150 Hz)
Ambient Air Temperature for Storage
-40 to 185°F (-40 to 85°C)
Shock Resistance
15 gn in operation
Connections Terminals
Faston terminals
Drop-out Voltage Threshold
>= 0.15 Uc AC; >= 0.1 Uc DC
Power consumption in VA
1.6 VA AC
Product Certifications
UL; CE; CSA
Voltage Range
0.8...1.1 Un AC/DC

Description

General Purpose Relay, Base Shape Square, Coil Voltage 24V AC, Contact Form SPDT, Current Rating 15 A, Electrical Connection Faston Terminal, Number of Pins 5, Status Indicator Mechanical Flag, Contact Rating (AC) 10 A @ 151/277V, 15 A @ 120 to 277/120/150/250V (NO), 7.55 A @ 250V (NC), Contact Rating (DC) 15 A @ 28V (NO), 7.55 A @ 28V (NC), Horsepower @ 120V AC 1/2 hp, Horsepower @ 240V AC 1 hp, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 1.39 in, Body Height 1.07 in
