Shop SCHNEIDER ELECTRIC

Variable Frequency Drive, 2 HP, 230VAC, Altivar

  • Mfr # ATV12HU15M3
  • Zoro # G0291907
product price:
$
375.99
/ea
Free Shipping & Returns

Key Features

Max. HP
2 hp
Input Voltage
200-240V AC
Output Voltage
200-240V AC
Input Phase AC
Three
Enclosure
Open
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ATV12HU15M3
Zoro #
G0291907
UPC #
785901590132
Country of Origin
Indonesia

Dimensions

Depth
5.17 in
Width
4.13 in
Height
5.12 in
Overall Height
5 5/8 in
Overall Width
4 1/8 in
Overall Depth
5 1/8 in

Details

Item
Variable Frequency Drive
Max. HP
2 hp
Input Voltage
200-240V AC
Output Voltage
200-240V AC
Input Phase AC
Three
Enclosure
Open
Max. Output Amps
7.5 A
Output Phase AC
Three
With Bypass / No Bypass
No Bypass
With Line Contactor / No Line Contactor
No Line Contactor
Torque @ 1 Hz
120%
For Use With
3-Phase Inverter Duty Motor
Digital Readout
Yes
Control Type
Keypad, Modbus, Remote Keypad
Starting Torque
170 %
Protection
Against Input Phase Loss in Three-Phase, Line Supply Overvoltage, Line Supply Undervoltage, Overcurrent Between Output Phases and Earth, Overheating Protection, Short-Circuit Between Motor phases, Thermal Motor Protection via the Drive by Continuous Calculation of I²t
Output Frequency Range
0.5 to 400 Hz
Control Method
Keypad or Remote Keypad or Modbus
Display Type
LED
Input Frequency
60/50 Hz
Start/Stop Control
Programmable
Adjustable Deceleration Time
0 to 999.9 sec
Adjustable Acceleration Time
0 to 999.9 sec
Key Pad Lockout
Yes
Dynamic Braking
No
Displays
LED
Accepts Input Control Signal
Yes
Standards
UL, C-tick, NOM, GOST, CSA
Ethernet Port Included
No
Output Voltage Range
170V AC to 264V AC
Brake Chopper Included
No
Enclosure Rating
NEMA 1
Application
Ironing Textile, Mixer Commercial Equipment, Other Application Commercial Equipment
Input Voltage Range
200 to 240V AC
Maximum Output Power
2 hp
Number of Outputs
(1) Analog; (2) Discrete
Torque Application
Constant Torque, Variable Torque
Output Type
Analog
Style
Heat Sink
Input Type
Analog, Digital
Color
Black
Maximum Output Current
7.5 A
Number of Inputs
(2) Analog; (4) Discrete
Series
Altivar 12
Output Frequency - Minimum
400 Hz
Output Frequency - Maximum
0.5 Hz
Number of Inputs - Analog
2
Output Current - Maximum
7.5 A
Includes Heat Sink
Yes
Output Horsepower
2 hp
Bypass Design
No Bypass
Includes Brake Chopper
No
NEMA Rating
NEMA 1
Line Contactor Design
No Line Contactor
Output Phase
Three
Number of Outputs - Analog
1
Input Phase
Three
Includes Ethernet Port
No
Product Type
Variable Frequency Drive
Keypad Lockout
Yes
IP Rating
IP21
Wire Color
Black
Container Type
Heat Sink
Sensor Body Style
Heat Sink

Description

Variable Frequency Drive, Input Voltage 200-240V AC, Input Phase AC Three, Input Frequency 60/50 Hz, Maximum Output Power 2 hp, Maximum Output Current 7.5 A, Output Voltage 200-240V AC, Output Phase AC Three, Output Frequency Range 0.5 to 400 Hz, Enclosure Rating NEMA 1
