Base Unit 6ES71936BP000BA0

  • Mfr # 6ES7193-6BP00-0BA0
  • Zoro # G008131642
product price:
$
39.15
/ea

Key Features

Width
15 mm
Height
117 mm
Depth
35 mm
UNSPSC (15)
32-15-17-04
Conductor Cross-Section, Min.
0.14 mm²; AWG 26
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
6ES7193-6BP00-0BA0
Zoro #
G008131642
UPC #
40892933550
Country of Origin
Germany
UNSPSC (15)
32-15-17-04
Conductor Cross-Section, Min.
0.14 mm²; AWG 26
External Protection for Power Supply Lines
Yes; 24 V DC/10 A miniature circuit breaker with type B or C tripping characteristic
Isolation Tested With
707 V DC (type test)
For Process Terminals, Max.
2 A
Horizontal Installation, Max
60°C
Vertical Installation, Max.
50°C
Automatic Encoding
Yes
Rated Value (DC)
24 V
Mains Filter Integrated
No
Terminal Type
Push-in terminal
Product Group
4520
For P1 and P2 Bus, Max.
10 A
Product Type Designation
BU type A0
Conductor Cross-Section, Max.
2.5 mm²; AWG 14
Number of Terminals with Connection to P1 and P2 Bus
2; Pro slot
Number of Process Terminals to I/O Module
16; Pro slot
Number of Terminals to AUX Bus
0
Installation Altitude Above Sea Level, Max.
2 000 m; On request: Installation altitudes greater than 2 000 m
Horizontal Installation, Min.
-30°C
eClass (9.1)
27-24-26-03
Number of Add-on Terminals
0
Vertical Installation, Min.
-30°C
HW Functional Status
From FS06
For Process Terminals
CC00 to CC09

Dimensions

Width
15 mm
Height
117 mm
Depth
35 mm

Description

6Es71936Bp000Ba0 Base Unit Type A0 Bu15P16A02B Without Aux Terminals Bridged To The Left
