Operator Interface 6AV21240QC020AX1

Mfr # 6AV2124-0QC02-0AX1
Zoro # G608131684

6,587.99

Free Shipping & Returns

Key Features

Number of HW interfaces serial RS232

SW interfaces present

min. supply voltage with DC

19 volt

Number of HW interfaces PROFINET

Number of HW interfaces serial TTY

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: 6AV2124-0QC02-0AX1
Zoro #: G608131684
UPC #: 804766523915
Country of Origin: Germany

Dimensions

Width of front: 415 millimetre
Height of front: 310 millimetre
Installation depth: 75 millimetre

Details

Number of HW interfaces serial RS232: 0
SW interfaces present: No
min. supply voltage with DC: 19 volt
Number of HW interfaces PROFINET: 2
Number of HW interfaces serial TTY: 0
Number of levels, password protection: 50
max. number of pixels, horizontal: 1280
number of system buttons: 0
description of product type: TP1500 Comfort
Touch screen present: Yes
Number of colors/shades of gray of the display: 16777216
Min. operating temperature: 0 degree_Celsius
Manufacturer product family: HMI
Degree of protection (IP), front side: IP65
Max. operating temperature: 50 degree_Celsius
max. supply voltage with DC: 28.8 volt
Number of HW interfaces serial RS422: 0
numeric keyboard present: Yes
Manufacturer product root: Comfort Panel
number of grey scales: 0
Number of HW interfaces, other: 0
Number of HW interfaces parallel: 0
Pressure output present: Yes
useable project memory/user memory: 24000 kilobyte
Display, color present: Yes
Number of HW interfaces serial RS485: 1
number of buttons with LED: 0
Supply voltage type: DC
Display type: TFT
wall mounting/direct mounting possible: No
max. number of pixels, vertical: 800
number of programmable function keys: 0
Number of HW interfaces Industrial Ethernet: 2
Monitor diagonal: 15.4 inch
Process value display (output) possible: Yes
Number of HW interfaces Wireless: 0
Process value provision (input) possible: Yes
Bearing track assembly possible: No
Message display present: Yes
Alpha keyboard present: Yes
Messaging system (including buffer and acknowledgement) present: Yes

Description

6Av21240Qc020Ax1 Operator Interface Touch Screen Simatic Hmi Tp1500 Comfort Panel 15 In Widescreen Tft Display Profinet Interface
