  9. FloatSwitch, 25ft, 125VAC
No Product Image Available

FloatSwitch, 25ft, 125VAC

  • Mfr # 25MEGANCEZ

  • Zoro # G815822399

product price: $101.99
/ea
Free Shipping & Returns

Key Features

Manufacturers Warranty Length
5 yr
Mounting Bracket Material
Stainless Steel
Float Material
Polypropylene
Contact Form
Normally Closed
Float Length
4 7/8 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
25MEGANCEZ
Zoro #
G815822399
UPC #
-
Country of Origin
United States

Dimensions

Manufacturers Warranty Length
5 yr
Float Length
4 7/8 in
Cord Length
25 ft
Float Diameter
2 3/4 in

Details

Mounting Bracket Material
Stainless Steel
Item
Float Switch
Float Material
Polypropylene
Contact Form
Normally Closed
Standards
CSA, UL Listed
Includes
Mounting Bracket
Series
EZconnex
Switch Type
Tether Float
Counterweight Type
No Counterweight
Actuation Method
Mechanically-Activated
Running Current - Maximum
1 A
Switch Duty
Control Duty
Off Point
1 1/2 in Above Horizontal
Number of Floats
1
Compatible Pump Type
Sewage Pump
Liquid Temperature - Maximum
140 Degrees F
Compatible Manufacturer Part Number
25MEGANCEZ
NEC Cord Designation
SJOW
On Point
1 1/2 in Below Horizontal
Electric Load Current - Minimum
1 mA @ 125V AC, 1 mA @ 30V DC, 1 mA @ 4V DC
Electric Load Current - Maximum
0.1 A @ 30V DC, 1 A @ 125V AC
Electrical Connection
2-Conductor Wire Leads
Rated Voltage
125V AC
Starting Current - Maximum
1 A
Mounting Hardware Included
Mounting Bracket

Description

Float Switch

Restrictions

This is a restricted item in the USA. It cannot be used for potable water applications.
