Push-Fit Elbow, Elbow
Mfr # KRL06-G03
Zoro # G316330072
product price:Â
$
4.99
/ea
Sold in multiples of 10 for $49.90
Key Features
Standards
RoHS
Color
Black
Application
Vacuum
Fitting Material
Polybutylene
Fitting Side 1 Tube Outer Diameter
6 mm
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- KRL06-G03
- Zoro #
- G316330072
- UPC #
- -
- Country of Origin
- Japan
Dimensions
- Fitting Side 1 Tube Outer Diameter
- 6 mm
- Fitting Thread Size
- 3/8
- Fitting Side 2 Pipe Size
- 3/8 in
- Overall Length
- 20 mm
- Wire Rope Length
- 20 mm
Details
- Item
- Push-Fit Elbow
- Standards
- RoHS
- Color
- Black
- Application
- Vacuum
- Fitting Material
- Polybutylene
- Operating Temperature - Maximum
- 140 Degrees F
- For Media Type
- Compressed Air, Non-Potable Water
- Operating Temperature - Minimum
- 23 Degrees F
- Fitting Shape
- Elbow
- Release Type
- Collet
- Fitting Side 1 Connection Type
- Push-to-Connect
- Operating Pressure - Maximum
- 1 MPa
- Compatible Tube Material
- Polyurethane, Nylon
- Series
- KR
- Resistance Properties
- Flame-Resistant
- Fitting Side 2 Connection Type
- BSPT
- Includes Pre-Applied Thread Sealant
- Pre-Applied Thread Sealant Not Included
- Connector Type
- Adapter
- Fitting Features
- Swivel
Description
Push-Fit Elbow, Application Vacuum, Fitting Material Polybutylene, Fitting Thread Size 3/8, Material Grade Not Applicable, Color Black, Includes Pre-Applied Thread Sealant Pre-Applied Thread Sealant Not Included, Overall Length 20 mm, Release Type Collet, Standards RoHS, Compatible Copper Tube Size Not Applicable, Compatible Copper Tube Type Not Applicable, Compatible Tube Material Polyurethane, Nylon, Resistance Properties Flame-Resistant, System of Measurement Not Applicable
