Square D Control Transformer, 150 VA, Not Rated, 115/230V AC, 380/400/415V 9070T150D33 - main

Control Transformer, 150 VA, Not Rated, 115/230V AC, 380/400/415V

  • Mfr # 9070T150D33

  • Zoro # G0573006

product price: $189.99
/ea
Free Shipping & Returns

Key Features

Input Voltage - Transformer
380/400/415V
Output Voltage
115/230V AC
Power Rating
150 VA
Phase
1
Hz - Electrical
50/60 Hz
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9070T150D33
Zoro #
G0573006
UPC #
785901845645
Country of Origin
Mexico

Dimensions

Overall Height
3.2 in
Overall Width
3 3/4 in
Overall Depth
3.59 in
Manufacturers Warranty Length
1 yr

Details

Item
Control Transformer
Input Voltage - Transformer
380/400/415V
Output Voltage
115/230V AC
Power Rating
150 VA
Phase
1
Hz - Electrical
50/60 Hz
NEMA Enclosure Rating
Not Rated
Green Environmental Attribute
Mercury Free; Pvc Free
Standards
CSA file LR37055 guide 184-N-90; UL listed file E61239
Primary Connection
Screw clamp terminals
Winding Material - Transformer
Copper
Enclosure Type
Open
Material
Copper: winding
Insulation Max. Temp.
105 °C
Secondary Connection
Screw clamp terminals
Temperature Rise
55°C
Insulation Temperature
221°F (105°C)
Primary To Secondary Voltage
380/400/415 V 115/230 V
Fingersafe Cover Compatibility
FSC1
Pvc Free
Yes
Range of Product
T
Rated Power In Va
150 VA UL, 150 VA CSA, 150 VA NOM, 150 VA CE
Nema Degree of Protection
not rated (open device)

Description

Xfmr Control 150Va Multiple Voltages
