Shop SQUARE D

Manual Motor Starter, Not Applicable, 3 P, 3 Phase, Selector Switch, 25 A

  • Mfr # GV2P22

  • Zoro # G0646712

product price:
$
281.99
/ea
Free Shipping & Returns

Key Features

Number of Poles
3
Operator
Selector Switch
Phase
3
Current AC
25 A
Series
TeSys Deca
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
GV2P22
Zoro #
G0646712
UPC #
785901832973
Country of Origin
Thailand

Dimensions

Overall Depth
3.82 in
Overall Width
1.77 in
Overall Height
3.5 in

Details

Item
Manual Motor Starter
Number of Poles
3
Operator
Selector Switch
Phase
3
Current AC
25 A
Series
TeSys Deca
Standards
ATEX Compliant, BV, CCC, CSA, DNV-GL, EAC, EN/IEC 60947-2, EN/IEC 60947-4, LROS, RINA, UKCA, UL Listed
Pilot Light
Yes
HP @ 3 Phase - 575V
20 hp
Description/Special Features
Reliable Overload Protection
Phase Loss Sensitivity
Yes
HP @ 3 Phase - 460-575V
15/20
HP @ 1 Phase - 230V
3 hp
Horsepower @ Single Phase - 120V AC
2 hp
Minimum Overload Relay Current Setting
20 A
Horsepower @ Three Phase - 208V AC
5 hp
Overload Protection Type
Thermal
IP Rating
IP20
Horsepower @ Three Phase - 600V AC
20 hp
Horsepower @ Three Phase - 480V AC
15 hp
Frequency
50/60 Hz
Maximum Overload Relay Current Setting
25 A
Starter Style
IEC
Minimum Operating Temperature
-4 Degrees F
Maximum Operating Temperature
140 Degrees F
NEMA Enclosure Rating
No Enclosure
Mechanical Operating Durability
100,000
Horsepower @ Single Phase - 240V AC
3 hp
Terminal Connection Type
Screw Clamp Terminals
Status Indicator
LED Indicator
Resistance Properties
Fire Resistant
Includes Pilot Light
No
Horsepower @ Three Phase - 240V AC
7 1/2 hp
Electrical Operating Durability
100,000
Maximum Voltage Rating
600V AC
Product Name
TeSys GV2 || TeSys Deca
Color
dark grey
[Uimp] Rated Impulse Withstand Voltage
6 kV IEC 60947-2
Utilisation Category
category A IEC 60947-2 || AC-3 IEC 60947-4-1
Tightening Torque
1.7 N.m screw clamp terminal
Operating Altitude
6561.68 ft (2000 m)
Phase Failure Sensitivity
yes IEC 60947-4-1
Power Dissipation Per Pole
2.5 W
Fixing Mode
35 mm symmetrical DIN rail clipped || panel screwed with 2 x M4 screws)
Rated Duty
continuous IEC 60947-4-1
Range
TeSys Deca
Trip Unit Technology
thermal-magnetic
Network Type
AC
Mechanical Robustness
shocks 30 Gn for 11 ms || vibrations 5 Gn, 5...150 Hz
Magnetic Tripping Current
327-327 A
Ambient Air Temperature For Storage
-40-80°C
Climatic Withstand
IACS E10
Fire Resistance
960°C IEC 60695-2-11
Ik Degree Of Protection
IK04
Suitability For Isolation
yes IEC 60947-1§ 7-1-6
Device Application
motor protection
Thermal Protection Adjustment Range
20-25 A IEC 60947-4-1
Motor Power Kw
11-11 kW 400/415 V AC 50/60 Hz || 15-15 kW 500 V AC 50/60 Hz
Device Short Name
GV2P
Rated Service Short-Circuit Breaking Capacity
100 % 230/240 V AC 50/60 Hz IEC 60947-2 || 50 % 400/415 V AC 50/60 Hz IEC 60947-2 || 75 % 440 V AC 50/60 Hz IEC 60947-2 || 75 % 500 V AC 50/60 Hz IEC 60947-2 || 100 % 690 V AC 50/60 Hz IEC 60947-2

Description

Manual Motor Starter, NEMA Size Not Applicable, Horsepower @ Single Phase - 120V AC 2 hp, Horsepower @ Single Phase - 240V AC 3 hp, Maximum Voltage Rating 600V AC, Number of Poles 3, Operator Selector Switch, Phase Three, Current AC 25 A, Horsepower @ Three Phase - 208V AC 5 hp, Horsepower @ Three Phase - 240V AC 7 1/2 hp, Horsepower @ Three Phase - 480V AC 15 hp, Series TeSys Deca, Horsepower @ Three Phase - 600V AC 20 hp, Maximum Overload Relay Current Setting 25 A
