Miniature Circuit Breaker, E FRAME Series, 100A, 2 Pole, 277/480V AC, 65kA at 120V AC
Mfr # EGB24100
Zoro # G0845909
product price:Â
$
1,139.99
/ea
Free Shipping & Returns
Key Features
Series
E FRAME
Number of Poles
2
AC Voltage Rating
277/480V AC
Circuit Breaker Type
Standard
Circuit Breaker Actuator
Toggle
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- EGB24100
- Zoro #
- G0845909
- UPC #
- 785901128595
- Country of Origin
- Korea, Republic of
Dimensions
- Frame Size
- 125A/EGB
- Width
- 1.96 in
- Depth
- 4.05 in
- Height
- 5.66 in
- Min. Wire Size
- 12 AWG (Al), 14 AWG (Cu)
- Max. Wire Size
- 2/0 AWG (Cu/Al)
Details
- Item
- Miniature Circuit Breaker
- Series
- E FRAME
- Amps
- 100 A
- Number of Poles
- 2
- AC Voltage Rating
- 277/480V AC
- Circuit Breaker Type
- Standard
- Circuit Breaker Actuator
- Toggle
- Circuit Breaker Mounting Style
- Bolt On
- Max. AIR Rating
- 65kA at 120V AC
- Trip Type
- Thermal Magnetic
- Terminal Connection
- Lugs
- DC Voltage Rating
- Not Rated
- Application
- HACR rated Applications
- Standards
- cULus
- For Use With
- NF Panelboard Accessory, NF Panelboards
- Interrupt Rating
- 35 kA at 480Y/277V AC, 65 kA at 120/240V AC
- High Amp Trip Setting
- 2300 A
- Features
- Mercury Free
Description
Miniature Circuit Breaker 480Y/277V 100A, Series EGB
