  9. Miniature Circuit Breaker, E FRAME Series, 80A, 3 Pole, 600V AC, 25kA at 120V AC
Square D Miniature Circuit Breaker, E FRAME Series, 80A, 3 Pole, 600V AC, 25kA at 120V AC EDB36080 - main

Miniature Circuit Breaker, E FRAME Series, 80A, 3 Pole, 600V AC, 25kA at 120V AC

  • Mfr # EDB36080

  • Zoro # G0845881

product price: $878.99
/ea
Free Shipping & Returns

Key Features

Series
E FRAME
Number of Poles
3
AC Voltage Rating
600V AC
Circuit Breaker Type
Standard
Circuit Breaker Actuator
Toggle
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
EDB36080
Zoro #
G0845881
UPC #
785901235088
Country of Origin
Mexico

Dimensions

Frame Size
125A/EDB
Width
2.94 in
Depth
4.05 in
Height
5.66 in
Min. Wire Size
12 AWG (Al), 14 AWG (Cu)
Max. Wire Size
2/0 AWG (Cu/Al)

Details

Item
Miniature Circuit Breaker
Series
E FRAME
Amps
80A
Number of Poles
3
AC Voltage Rating
600V AC
Circuit Breaker Type
Standard
Circuit Breaker Actuator
Toggle
Circuit Breaker Mounting Style
Bolt On
Max. AIR Rating
25kA at 120V AC
Trip Type
Thermal Magnetic
Terminal Connection
Lugs
DC Voltage Rating
Not Rated
For Use With
NF Panelboard Accessory, NF Panelboards
Interrupt Rating
14 kA at 600Y/347V AC
High Amp Trip Setting
2300 A
Standards
cULus
Application
HACR rated Applications
Features
Mercury Free
Breaking Capacity Code
D
Ambient Air Temperature For Operation
104°F (40°C)
Module Type
E-Frame
Tightening Torque
34.52 lbf.in (3.9 N.m) 0.00 to 0.01 in² (2.5 to 6 mm²) (AWG 14 to AWG 10); 49.56 lbf.in (5.6 N.m) 0.02 to 0.11 in² (10 to 70 mm²) (AWG 8 to AWG 2/0)
AWG Gauge
AWG 12 to AWG 2/0 aluminium; AWG 14 to AWG 2/0 copper
Breaking Capacity
14 kA 600Y/347 V AC
Circuit Breaker Application
HACR rated
Protection Type
Overload; Short-circuit
Holding Current
1000 A
Local Signalling
Trip indicator

Description

Miniature Circuit Breaker 600V 80A, Series EDB
