Miniature Circuit Breaker, HOMELINE Series, 110A, 2 Pole, 240V AC, 10kA at 240V AC
Mfr # HOM2110
Zoro # G2844825
product price:Â $164.99
/ea
Free Shipping & Returns
Key Features
Series
HOMELINE
Number of Poles
2
AC Voltage Rating
240V AC
Circuit Breaker Type
Standard
Phase
1
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
MFR #
HOM2110
Zoro #
G2844825
UPC #
785901114826
Country of Origin
Mexico
Dimensions
Frame Size
100A/HOM
Width
2 in
Depth
2.98 in
Height
3.13 in
Min. Wire Size
4 AWG
Max. Wire Size
2 AWG
Wire Size
1 x AWG 4 to AWG 2/0 ( aluminium/copper )
Length
3.13 in
Description
Miniature Circuit Breaker, Amps 110 A, AC Voltage Rating 120/240V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating Not Rated, Circuit Breaker Actuator Paddle, Circuit Breaker Mounting Style Plug In, Compatible Panelboard/Load Center Series HOM, Phase Single, Series HOM, Max. AIR Rating 10kA at 120/240V AC, For Use With Homeline Load Center, Terminal Connection Lug, Frame Size 100A/HOM, Length 3.13 in, Width 2 in, Depth 2.98 in, Min. Operating Temp. 77 Degrees F
