  5. Molded Case Circuit Breaker, POWERPACT J Series, 225A, 2 Pole, 600V AC, 25kA at 240V AC
Square D Molded Case Circuit Breaker, POWERPACT J Series, 225A, 2 Pole, 600V AC, 25kA at 240V AC JDL26225 - main
Shop SQUARE D

Molded Case Circuit Breaker, POWERPACT J Series, 225A, 2 Pole, 600V AC, 25kA at 240V AC

  • Mfr # JDL26225

  • Zoro # G1114741

product price:  $1,740.99
/ea
Free Shipping & Returns

Key Features

Series
POWERPACT J
Number of Poles
2
AC Voltage Rating
600V AC
Circuit Breaker Type
Standard
Phase
1
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
JDL26225
Zoro #
G1114741
UPC #
785901623182
Country of Origin
Mexico

Dimensions

Frame Size
250A/JD
Width
2.70 in
Depth
5 in
Height
7-1/2 in
Max. Wire Size
300 MCM
Min. Wire Size
3/0 AWG

Details

Item
Molded Case Circuit Breaker
Series
POWERPACT J
Amps
225A
Number of Poles
2
AC Voltage Rating
600V AC
Circuit Breaker Type
Standard
Phase
1
Circuit Breaker Actuator
Toggle
Circuit Breaker Mounting Style
Surface Mount/DIN Rail
Max. AIR Rating
25kA at 240V AC
Trip Type
Thermal Magnetic
Instantaneous Trip
Adjustable
Terminal Connection
Lugs
DC Voltage Rating
250V DC
High Amp Trip Setting
2,250 A
Standards
BS, CCC, CE Marked, CEI, CSA Certified, Federal Specification W-C-375B/GEN, HACR, HID, IEC, NEMA, NMX, NOM, SWD, UL Listed, UNE, UTE, VDE
Low Amp Trip Setting
1,125 A
Application
HACR rated Applications; Distribution
Interrupt Rating
25 kA at 220/240V AC, 18 kA at 380/440/415/480V AC, 14 kA at 500/525/600V AC, 20 kA at 250/500V DC
Features
Mercury Free; PVC Free

Description

Molded Case Circuit Breaker, 225 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 25kA at 240V AC, For Use With -, Series JD, High Amp Trip Setting 2,250 A, Low Amp Trip Setting 1,125 A, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating 250V DC, Terminal Connection Line/Load Lug, Trip Type Thermal Magnetic, Phase Single, Instantaneous Trip Adjustable, Phase Connection Not Applicable, Frame Size 250A/JD, Circuit Breaker Mounting Style Free Standing, Height 7.5 in, Width 2.7 in
