Molded Case Circuit Breakers
Mfr # HLL36100M73
Zoro # G523523113
product price:Â
$
1,994.99
/ea
Free Shipping & Returns
Key Features
Instantaneous Trip
Instantaneous
Number of Poles
3
Standards
CSA, NOM, UL
Height
4.09 in
Amps
100 A
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- HLL36100M73
- Zoro #
- G523523113
- UPC #
- 785901914006
- Country of Origin
- Mexico
Dimensions
- Height
- 4.09 in
- Depth
- 3.4 in
- Width
- 4.09 in
- Max. Wire Size
- 3/0 AWG
- Min. Wire Size
- 14 AWG
Details
- Instantaneous Trip
- Instantaneous
- Number of Poles
- 3
- Standards
- CSA, NOM, UL
- Amps
- 100 A
- Max. Operating Temp.
- 158 Degrees F
- AC Voltage Rating
- 600V AC
- Min. Operating Temp.
- -13
- Circuit Breaker Mounting Style
- Unit Mount
- Item
- Molded Case Circuit Breaker
- Circuit Breaker Type
- Motor Circuit Protector
- Terminal Connection
- Lugs
- Max. AIR Rating
- 50kA at 600V AC
Description
Molded Case Circuit Breaker, 100 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 50kA at 600V AC, Circuit Breaker Type Motor Circuit Protector, Number of Poles 3, Terminal Connection Lugs, Trip Type Thermal Magnetic, Instantaneous Trip Instantaneous, Circuit Breaker Mounting Style Unit Mount, Height 4.09 in, Width 4.09 in, Depth 3.4 in, Min. Wire Size 14 AWG, Max. Wire Size 3/0 AWG, Max. Operating Temp. 158 Degrees F, Min. Operating Temp. -13, Standards CSA, NOM, UL
