  11. Power Distribution Block, 1 Pole, 380 A Copper, 600 V AC/DC, Surface Mount
Square D Power Distribution Block, 1 Pole, 380 A Copper, 600 V AC/DC, Surface Mount 9080LBC163106 - main

Power Distribution Block, 1 Pole, 380 A Copper, 600 V AC/DC, Surface Mount

  • Mfr # 9080LBC163106

  • Zoro # G0853636

product price: $178.99
/ea
Free Shipping & Returns

Key Features

Maximum Voltage
600 V AC/DC
Line Connections/Pole
1
Load Connections/Pole
6
Line Side Connection Type
Lug
Load Side Connection Type
Lug
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9080LBC163106
Zoro #
G0853636
UPC #
785901097617
Country of Origin
United States

Dimensions

Length
4 in
Width
1.94 in
Depth
2.61 in
Wire Strip Length
Line 1.06 in; Load 1 in bottom; Load 1.56 in top
Height
4 in
For Line Copper Wire Size - Minimum
4 AWG
For Line Copper Wire Size - Maximum
500 kcmil
For Load Copper Wire Size - Minimum
14 AWG
For Load Copper Wire Size - Maximum
2 AWG

Details

Item
Power Distribution Block
Maximum Current - Copper Conductor
380 A
Maximum Voltage
600 V AC/DC
Number of Poles
1
Line Connections/Pole
1
Load Connections/Pole
6
Line Side Connection Type
Lug
Load Side Connection Type
Lug
Housing Material
Phenolic
Maximum Operating Temperature
302 Degrees F
Mounting Type
Surface Mount
Standards
CSA file 70361 class 6228 01, UL recognized E60616 CCN XCFR2, CE
Short Circuit Current Rating
100 kA UL 508 A
Features
Mercury Free
Min. Operating Temp.
-40°F
Ambient Air Temperature For Operation
-40-302°F
Range of Product
9080LB
[Ue] Rated Operational Voltage
600 V AC/DC
Product Compatibility
9080LB31
Number of Cables
line 6 , AWG 4...500 kcmil, copper, load 1 , AWG 14...AWG 2, copper
[Ics] Rated Service Breaking Capacity
100 kA UL 508 A
End Barrier
9080LB31
Terminal Tightening Torque
Load lug 40 lbf.in (4.52 N.m) AWG 8 copper; Load lug 35 lbf.in (3.95 N.m) AWG 14 to AWG 10 copper; Line lug 375 lbf.in (42.37 N.m) AWG 4 to 500 kcmil copper; Load lug 50 lbf.in (5.65 N.m) AWG 2 copper; Load lug 45 lbf.in (5.08 N.m) AWG 6 to AWG 4 copper

Description

Power Distribution Block 600V 380A Tlb
